The Capacity Doctrine

A military-grade bulkhead door closing in front of a corridor full of heavy machinery, lit by a single amber warning light.

On 2026-04-23 the Mini kernel-panicked twice. On 2026-04-24 LM Studio stalled at 99 percent loading a model while the VM’s qemu process sat SIGSTOP’d for two hours in silence. Different symptoms, same disease: multiple memory-heavy services competing for the same unified RAM pool with no admission control. Each service trusted the kernel to find it space. The kernel, overwhelmed, either panicked or paused at random. We discovered the ceiling by hitting it.

The Capacity Doctrine is the immune-system answer: refuse bad loads up front instead of reacting to failures downstream.

Three Rules

Rule 1: Declare your weight

Every heavyweight service has a ram_budget_mb number in ~/.sanctum/capacity.yaml. No budget, no admission. The number is measured with vmmap --summary at peak inference, then rounded up. A false refuse is strictly cheaper than an OOM freeze.

Rule 2: Admission controller gates every load

sanctum-admit on port 2189 computes free = pool − Σ(loaded.budget) from a live ps scan. Loading a service is admitted only if new.budget ≤ free AND none of its exclusive_with neighbours are currently loaded. Refusals return HTTP 409 with the blocking service name and the remedy command.

Rule 3: Nothing critical gets suspended

qemu, sanctumd, sanctum-mlx, signal-cli, WindowServer are in the sentinel safelist. A watcher loop in sanctum-admit scans ps stat every ten seconds; any critical process in state T gets kill -CONT within a single interval, plus a notification to the dashboard and (if severe enough) Signal.

The Ledger Is Live

The admission ledger is not a state file that can drift from reality. On every /admit or /capacity request, the daemon re-scans ps output and reconciles against capacity.yaml. A service is loaded iff either:

its process_pattern regex matches some live command line, or
its loaded_check_cmd exits zero within two seconds.

This means the ledger self-corrects across daemon restarts, unclean exits, and manual kill -9 — there is no state to repair because there is no stored state to corrupt.

The Exclusion Graph

Some services cannot coexist on a ~64 GB host. capacity.yaml names these explicitly:

sanctum-mlx:
  ram_budget_mb: 45000         # Qwen3.6-35B-A3B-4bit
  exclusive_with: [lmstudio-coder-14b]
  priority: 100

lmstudio-coder-14b:
  ram_budget_mb: 12000
  exclusive_with: [sanctum-mlx]
  priority: 50

Exclusion is symmetric and enforced at admission. The higher-priority service wins the tie when both are requested. Priority is also the tiebreaker when the sentinel has to choose between evicting workloads under duress.

Three Layers Of Defense

Layer	Purpose	When
Admission	Refuse loads that exceed headroom	Before anything allocates
Monitor	Catch half-loaded states and signal-stopped processes	Every 10s (state T), every 60s (inference probe)
Recovery	Unstick what slipped through	`kill -CONT` on T; `unload_cmd + load_cmd` after 3 probe failures

The layers are independent. Admission control alone would miss a runaway allocation that grew after load. Monitoring alone would miss the load that never should have started. Recovery alone is the old watchdog — it reacts too late. Together they form a control loop where every pathway back to a known-good state is explicit.

The CLI Is The Contract

The canonical way to load a heavy service is never lms load … or launchctl kickstart … directly. It is:

sanctum-admit load <service-name>

The CLI posts to /admit, and only if the HTTP response is 200 does it execute the service’s load_cmd. A refused load exits with code 2 and the remedy printed to stderr. Direct calls bypass admission — they’re permitted but discouraged, and the sentinel will still catch obvious misuse downstream.

Host Budget Math

Each host declares three numbers. The pool is derived:

hosts:
  manoir:
    ram_physical_mb: 65536    # Mac Mini M4 Pro, 64 GiB unified
    ram_reserved_mb: 12288    # macOS + WindowServer + user apps
    ram_safety_mb: 4096       # hard floor — never fill below
    # pool_mb = 65536 − 12288 − 4096 = 49152 MB

The safety margin is non-negotiable. We don’t allocate into it even if admission math says we could — it’s the buffer that keeps the kernel’s own memory-pressure machinery working. Hit the safety margin and you’re in the territory where jetsam starts SIGSTOPping random processes, which is where the 2026-04-24 incident came from.

What This Replaces

Before the doctrine, capacity was a hope. Services started on reboot, the OS sorted it out, and when it didn’t, the watchdog noticed eventually. The 2026-04-23 kernel panic and 2026-04-24 freeze were both perfectly-preventable incidents — we had the information to refuse those loads, we just weren’t asking.

After the doctrine, capacity is a refusal. The admission controller can point at any service, at any moment, and say “not this one, not now, here’s why, here’s the remedy.” That is the Apple-like part. That is the military-grade part.

The system no longer discovers the ceiling by hitting it.
