Requirements

Before installing Sanctum, make sure your environment meets the following requirements. The platform is designed for Apple Silicon Macs, with a Linux VM handling specific workloads. Yes, you are running an entire intelligence platform on a desktop computer the size of a sandwich. We will not apologize for this.

Hardware

Mac Mini (Required)

You will need a Mac Mini. The whole Mac Mini. Not an old one in a drawer — a current-generation Apple Silicon Mac Mini that you are prepared to leave running in a closet, silently orchestrating your domestic life like a very small, very expensive butler.

Component	Minimum	Recommended
Chip	M4	M4 Pro
RAM	16 GB	32 GB+
Storage	256 GB internal	1 TB+ internal
Network	Gigabit Ethernet	Gigabit Ethernet

Tip

The M4 Pro is recommended because local LLMs and Qwen3-TTS voice synthesis benefit significantly from the additional GPU cores and memory bandwidth. A base M4 will work, but expect slower inference and reduced model sizes. Think of it as the difference between a sports car and a sedan — both get you there, but one of them lets you run a 35-billion-parameter model without the fan spinning up like a jet engine.

External Storage (Optional)

An external drive is useful for offline knowledge bases (Kiwix), media libraries, and backups. Any USB-C or Thunderbolt drive will work. There is no strict performance requirement since these workloads are not latency-sensitive. Even your data gets to relax sometimes.

Satellite Nodes (Optional)

For multi-site deployments, satellite nodes can run on any Apple Silicon Mac. An M1 Mac Mini with 16 GB is sufficient for a satellite. If you are the kind of person who has multiple homes and wants AI agents in all of them, congratulations on both your real estate portfolio and your commitment to unnecessary complexity.

Software

Required

Install the following before proceeding to the installation guide. This is the part where you open Terminal and pretend you are in a movie.

macOS

Software	Version	Install
macOS	macOS 15 Sequoia minimum (26 Tahoe recommended)	System update
Homebrew	Latest	brew.sh
Python	3.12+	brew install python
Node.js	22+	brew install node or via fnm
Docker Desktop	Latest	docker.com
Lima	Latest	brew install lima (runs the Ubuntu VM on Apple Virtualization)
socket_vmnet	Latest	brew install socket_vmnet (host-only Mac↔VM bridge)
Git	Latest	brew install git (or Xcode CLI tools)

Ubuntu VM

Software	Version	Notes
Ubuntu	24.04 LTS	Installed as a Lima vz VM
Docker	Latest	apt install docker.io
Node.js	22+	Via NodeSource or fnm
SOPS	Latest	apt install sops or from GitHub releases
age	Latest	apt install age (for SOPS encryption)
SSH	OpenSSH 9+	Included with Ubuntu

Note

Lima runs the Ubuntu VM on Apple’s Virtualization Framework (vmType: vz) — no UTM GUI, no QEMU process. The one thing vz does not give you natively is host-only networking, so Sanctum backs the bridge interface with socket_vmnet running as root. Two tools, one VM, and the host-only network Apple forgot to ship. (Sanctum ran on QEMU/HVF until May 2026, when an idle-spin bug that pinned a core at 100% on a sleeping VM convinced us to switch. The fan thanked us.)

VM Specifications

When creating the Ubuntu VM with Lima, use these settings:

Setting	Value
Backend	Lima (vmType: vz, Apple Virtualization)
CPU cores	4
Memory	8 GB
Disk	100 GB
Bridge network	Host Only via socket_vmnet (vmnet host mode)
Internet	NAT interface, managed by Lima

The VM carries two interfaces. A host-only bridge (lima0) puts the Mac at 10.0.0.1 and the VM at 10.0.0.10 — that private wire is how every agent on the VM reaches services on the hub. A second NAT interface gives the VM its own outbound path to the internet for apt and git. Not solitary confinement, then; more like a studio apartment with one locked door to the haus and one window to the outside world.

Optional Components

These are not required for a basic installation but enable additional capabilities. Think of them as side quests.

Firewalla

A Firewalla in Router mode provides network-level security, DNS management, and device monitoring. The hub runs a Gold Pro, but any Router-mode Firewalla works. Sanctum includes a bridge service that talks to it over its P2P API on port 8833.

If you do not have a Firewalla, Sanctum will still function. Network management features will simply be unavailable, and you will have to monitor your network the old-fashioned way: by not monitoring it at all and hoping for the best.

Tailscale

Tailscale provides secure mesh networking between nodes. It is required for multi-node deployments (hub + satellite) and strongly recommended for remote access to your hub.

Install Tailscale on each node:

brew install --cask tailscale

Cloudflare Domain

A domain managed through Cloudflare enables secure public access to specific services (such as the Home Assistant dashboard or health endpoints) via Cloudflare Tunnel. The free Zero Trust plan is sufficient.

Local OpenAI-compatible inference (port 1234)

Sanctum expects a local OpenAI-compatible model server on port 1234, used as a primary or fallback provider. LM Studio is the easy on-ramp — install the app (or its lms CLI) and point it at :1234. The running hub currently serves that port with mlx_lm.server instead, a workaround for a cathedral bug from May 2026; the provider behind the socket is interchangeable as long as it speaks the OpenAI API on 1234.

iPhone Apps

These iOS apps integrate with Sanctum services on the hub.

App	Purpose	Required
Home Assistant Companion	HA remote control, presence detection, notifications	Yes
Health Auto Export	Push Apple Health data to health ingester	If health monitoring enabled
Tailscale	VPN mesh access to hub from anywhere	Recommended

Note

The HA Companion app provides presence detection (used by automations to know who is haus), actionable notifications, and location tracking. Health Auto Export sends hourly health data to the Cilghal health agent via a REST API automation. Your phone becomes a sensor that reports on you to your own haus. You volunteered for this.

Network Architecture

Sanctum expects the following network layout:

Internet
  |
Modem / ONT
  |
Firewalla WAN (Router mode)
  |
LAN (192.0.2.0/24, gateway .1)
  |-- Mac Mini (.10) -- Host Only bridge (10.0.0.0/24) -- Ubuntu VM (.10)
  |-- Orbi / Wi-Fi AP (AP mode)
  \-- Smart devices, speakers, etc.

Caution

The host-only bridge (10.0.0.0/24) is the only path between the VM and hub services — agent workloads on the VM talk to the Mac over that private wire and nowhere else. The VM does keep a separate NAT interface for outbound apt and git, so it is not air-gapped: it is firewalled by topology, not by amputation. If you want a true air-gap, drop the NAT NIC and proxy package installs through the Mac — but then you own the proxy, forever.

Verification

Before moving on, confirm you have the required tools installed:

# Check macOS version
sw_vers

# Check Homebrew
brew --version

# Check Python
python3 --version

# Check Node.js
node --version

# Check Docker
docker --version

# Check Lima (runs the VM) and socket_vmnet (the host-only bridge)
limactl --version
which socket_vmnet

If all of those commands returned something other than an error, you are ready. If any of them failed, fix it now. The installation guide is patient, but it will not hold your hand through missing dependencies.

Once everything checks out, proceed to Installation.
