Services

Every Sanctum service has an enabled flag in instance.yaml. Disabled services are skipped by the plist generator, excluded from the dashboard, and ignored by the watchdog. This page is the authoritative catalog of all services in the platform.

🔍 Hover to zoom

There are a lot of them. What started as “I’ll just automate the speakers” has become something that requires its own port allocation strategy and a documentation site. This is either a haus automation system or a small government. The line blurred around service number twelve and never came back. Thirty-eight services now — enough to staff two Habs benches on a good night, and they all think they’re the centreman. Each with a launchd unit, a port, a plist, and opinions about what should have been done on Tuesday.

Domain note (post-W6/W7, 2026-05-07/08)

Six P0 services — force-flow, proxyd, watchdog, mlx, ha-gateway, firewalla — were promoted from user-domain LaunchAgents (~/Library/LaunchAgents/, gui/501) to system-domain LaunchDaemons (/Library/LaunchDaemons/, system/) running as UserName=bert. They survive any reboot pattern, including a missing /etc/kcpassword. Tables on this page still say “LaunchAgent / Unit” because most services remain user-agents; mentally substitute “system-domain” for those six. Full story in the 2026-05-07 reboot-reveals field-note.

Core Services

A $600 aluminum rectangle shouldering the responsibilities of a small government. These six services are the load-bearing walls. Remove any one and the haus doesn’t just creak — it files a complaint with the watchdog, the dashboard goes red, and your family asks why the chat isn’t working during dinner.

Every hub node runs all of them. No exceptions, no “I’ll enable that later.” Later is where haus automation projects go to die.

Service	Port	LaunchAgent / Unit	Description
DenchClaw Gateway	1977	com.sanctum.gateway	Mac-side agent gateway. Runs Jocasta (the Archivist — CRM data and communications) and exposes the agent API.
Home Assistant	8123	Docker container	Home automation hub. Bridge-networked Docker container with HomeKit bridge on port 21063.
Command Center	1111	com.sanctum.dashboard	Web dashboard for service status, agent activity, and system health.
Health Center	2222	com.sanctum.health-center	Digital twin portal — health, wellness, and haushold telemetry. Twin twos for the twin.
Holocron (Dench)	1977	com.sanctum.dench	Family chat interface. Bound to LAN, token-authenticated. Accessible at http://holocron/.
Dench Proxy	80	com.sanctum.dench-proxy	LaunchDaemon (runs as root). Reverse proxy from port 80 to Holocron on port 1977.

Tip

The Dench Proxy is a LaunchDaemon, not a LaunchAgent. It runs as root to bind to port 80 and lives in /Library/LaunchDaemons/. Yes, one of the services runs as root so the family can type http://holocron/ instead of http://holocron:1977/. Vanity port. Worth it.

Note

Dench Proxy is currently disabled. Port 80 routing requires a LaunchDaemon and root privileges — most access now goes through Cloudflare Tunnel or Tailscale, which need neither.

Note

Holocron is currently disabled. The chat interface remains defined in configuration for future re-enablement but is not running on any hub node at present.

Config Example

services:
  openclaw_gateway:
    enabled: true
    port: 1977
  home_assistant:
    enabled: true
    port: 8123
    homekit_port: 21063
  dashboard:
    enabled: true
    port: 1111

AI Services

Five AI models sharing a single Mac Mini is either an act of architectural genius or the opening scene of a disaster movie. We’ve been running it for months. The jury remains out, but the Mac Mini hasn’t caught fire, so we’re calling it genius until the thermal paste says otherwise.

This is where Apple Silicon earns its keep. The M4 Pro runs local inference, text-to-speech, and a voice agent simultaneously — the kind of multitasking that would make an Intel chip file a workers’ comp claim.

Service	Port	Codename	LaunchAgent	Description
LM Studio	1234	—	com.sanctum.lmstudio-bridge	Local LLM inference for VM agents. Currently serving qwen2.5-coder-14b-instruct via socat bridge from 10.10.10.1:1234 to 127.0.0.1:1234. API key: lm-studio.
Council MLX	1337	leet — the local workhorse	com.sanctum.mlx	Pure-Rust sanctum-mlx server. Serves Qwen3.6-35B-A3B-4bit with TurboQuant Slice 4a fused Metal kernel. mTLS-only. The 27B-distilled era ended 2026-04-22 when the council moved to the 35B MoE.
TTS Voice	8008	BOOB — Yoda’s mouth	com.sanctum.yoda-tts-worker	Qwen3-TTS via mlx-audio (workers.tts_server). XTTS retired 2026-04-19 once Qwen3-TTS proved equal quality with lower memory pressure.
Voice Agent	1138	—	com.sanctum.voice-agent	Yoda voice interface. Integrates with Sonos speakers via the Sonos Bridge REST API on port 1969.
Sanctum Proxy	4040	.40 caliber — the gateway	com.sanctum.server	LLM routing proxy on port 4040 (binary: proxyd). Single Rust binary handling tiered model routing, prompt caching, request sanitization, PII scrubbing, and automatic fallback. KeepAlive enabled.
Memory Vault	42069	Nice.	com.sanctum.memory-vault	Long-term memory store for agent context. SQLite vault at ~/.sanctum/memory/.vault.db, consolidates every 6h. SSE transport for MCP clients.
Jina Reranker	42070	The Pair Port	com.sanctum.reranker	Jina v2 reranking server. Companion to Memory Vault on 42069 — the two travel together by design. Improves RAG precision for long-context memory queries.

Model Routing — 3-Tier Architecture

Agents use a 3-tier model strategy ranked by the Carmack Olympics benchmark system. The Smart Router dispatches each request based on model field, glob patterns, or intent keywords. When the primary tier is unavailable, traffic cascades down through the chain until it hits local Metal inference. The generator always kicks in.

Tier	Model	Port	Agents	Fallback
cloud	Claude Opus 4.7 (Anthropic)	:4040 proxy	Windu, Mothma, Jocasta	Coder-14B → Council MLX → error
council-ops	Qwen 2.5 Coder 14B (LM Studio)	:1234	Yoda, QuiGon, Ahsoka	Council MLX → error
council-secure	Gemma4+LoRA (sanctum-mlx)	:1337	Cilghal, Mundi	error
coder	Qwen 2.5 Coder 14B (LM Studio)	:1234	all coding tasks	Council MLX → error

Cloud tier runs through the Sanctum Proxy on :4040 with daily cost caps, audit logging, and automatic fallback to local models when the budget circuit breaker fires. The cloud proxy does not negotiate. It does math.

The Sanctum Proxy (port 4040) intercepts all requests and applies a 7-step pipeline before routing them to the appropriate model. Seven steps between an agent’s thought and the outside world. The TSA wishes they were this thorough.

0. Smart content-based routing (model field, glob patterns, intent keywords)
1. Anthropic prompt caching injection
2. Thinking block sanitization
3. Empty content block fixes
4. Context window truncation
5. Assistant message prefill stripping
6. PII anonymization for OpenRouter

Note

The Sanctum Proxy is a single Rust binary on port 4040. It handles model resolution, fallback routing, request sanitization, and content-based routing in one process. All external traffic enters through port 4040. One port, seven pipeline stages, and a hope that the content blocks aren’t empty again.

Config Example

services:
  lm_studio:
    enabled: true
    port: 1234
  council_mlx:
    enabled: true
    port: 1337
  voice_agent:
    enabled: true
    port: 1138
  qwen3_tts:
    enabled: true
    port: 8008
  proxy:
    enabled: true
    port: 4040

Network Services

Bridges and tunnels. The unglamorous plumbing that connects a closet-mounted Mac Mini to a router, a mesh access point, a VM with no internet, and the wider world beyond the front door. If the core services are the organs, these are the nervous system — delicate, invisible when they work, and the first thing you suspect when something goes wrong.

There are nine of them. Two are SSH tunnels. Two are mDNS broadcasters. One talks to the router by first authenticating through a cloud server three thousand miles away. One talks to Sonos speakers because Docker couldn’t. Home networking in 2026 is the kind of helpful that gets people killed in horror movies.

Service	Port	Codename	LaunchAgent	Description
SanctumBridge	4078	The FDA Neighbor	com.sanctum.bridge	Read-only HTTP proxy to FDA-protected SQLite databases (iMessage, WhatsApp, Contacts, Calendar). Jocasta-mcp queries through it so the MCP server itself doesn’t need Full Disk Access.
Firewalla Bridge	1984	Orwell — Big Brother watches	com.sanctum.firewalla	HTTP bridge to the Firewalla Purple router P2P API (port 8833). Bound to 0.0.0.0 so the VM can reach it. KeepAlive enabled.
Sonos Bridge	1969	—	com.openclaw.sonos-bridge	Native Mac SoCo REST API for 10 Sonos speakers. Replaces HA’s built-in Sonos integration. Handles TTS via XTTS, volume control, grouping, and announcements. KeepAlive enabled.
Orbi Bridge	18080 / 18085	—	com.sanctum.orbi-bridge	Socat bridge forwarding traffic from the VM to the Orbi access point (192.168.1.2 ports 80 and 5000). KeepAlive enabled.
Cloudflare Tunnel	—	—	com.sanctum.tunnel	Named tunnel sanctum-hub. Exposes health.example.net and ha.example.net via Cloudflare Zero Trust. KeepAlive enabled.
Network Control	4007	007 — licensed to ping	com.sanctum.ha-tunnel	SSH tunnel forwarding port 4007 to the VM for Home Assistant integrations.
Health Ingester	10101	binary heartbeat	com.sanctum.health-tunnel	SSH tunnel forwarding port 10101 to the VM for the health data ingester. KeepAlive enabled.
mDNS Alias	—	com.sanctum.mdns-docs	Broadcasts haus aliases (sanctum-hub.local, holocron.local, etc.) via mDNS for LAN discovery. KeepAlive enabled. Consolidated from the old mdns-alias / mdns-dench split.

Tunnel Routes

Two subdomains. Two Cloudflare Zero Trust routes. The entire external attack surface of the instance, right here in a table small enough to fit on a sticky note. That’s the goal. If your external exposure can’t fit on a sticky note, you have too much external exposure.

Subdomain	Local Target	Purpose
health.example.net	localhost:10101	Health data ingestion endpoint
ha.example.net	localhost:8123	Home Assistant remote access

Caution

The Firewalla Bridge requires cloud authentication to firewalla.encipher.io before it can issue local P2P commands. Keys are stored at ~/.sanctum/firewalla/keys/. So yes — to talk to the router sitting three feet away, we first authenticate through a cloud service. Home networking in 2026.

Config Example

services:
  firewalla_bridge:
    enabled: true
    port: 1984
  sonos_bridge:
    enabled: true
    port: 1969
  orbi_bridge:
    enabled: true
    port: 18080
    admin_port: 18085
  cloudflare_tunnel:
    enabled: true
    tunnel_name: sanctum-hub

System Services

The immune system. The janitors. The 3 AM shift workers nobody thanks until something rots. These services watch the other services, rotate secrets before they expire, file documents nobody asked them to file, and occasionally reorganize your music library while you sleep. The system watches itself with more dedication than most humans watch their own cholesterol.

Eight background agents and three supporting services, zero ports for most of them, and one that requires you to physically plug in a hard drive like it’s 2008. We contain multitudes.

Service	Port	LaunchAgent	Description
Watchdog	—	com.sanctum.watchdog	Runs every 600 seconds. Checks all enabled services and auto-heals failures via service-doctor.
Secret Rotation	—	com.sanctum.rotate-secrets	Runs on the 1st of each month at 3:30 AM. Rotates gateway tokens and updates Keychain entries.
iCloud Filer	—	com.sanctum.icloud-filer	Auto-filing daemon. Organizes documents from iCloud Drive into structured folders. KeepAlive enabled.
iCloud Backup	—	com.sanctum.icloud-backup	Periodic backup of Sanctum configuration and data to iCloud Drive.
VM Autostart (QEMU headless)	—	com.sanctum.vm-autostart	Launches QEMU headless on login, starts the Ubuntu VM, restores the bridge100 interface IP, and re-establishes the VM-facing LM Studio bridge on 10.10.10.1:1234.
Music Cleanup	—	com.sanctum.music-cleanup	Runs every Sunday at 3:15 AM. Organizes the Apple Music library via apple-music-organize.sh.
Kiwix	8888	com.sanctum.kiwix-serve	Offline knowledge library. Serves cached reference content. Requires external T9 drive. KeepAlive enabled with 30-second throttle.
Outline	3100	Docker container	Self-hosted wiki and documentation service. Provides a collaborative knowledge base for haushold documentation.
Jocasta MCP	CLI	CLI and Stdio RPC	The unified offline data proxy. Provides the Jedi Council safe, offline read-access to 16 disparate components: Apple Notes, Calendars, Contacts, Unified Logs, Maps, multiple messaging apps, and local file parsing.
Force Flow	4077	com.sanctum.force-flow	Notification triage and curfew enforcement engine. Mothma’s dispatch layer — decides what deserves attention and what gets filed under “haus is fine, stop asking.” M*A*S*H 4077th energy: triages the critical from the cosmetic with gallows humor and a functioning still.
SanctumBridge	4078	com.sanctum.bridge	FDA-privileged HTTP proxy to iMessage, WhatsApp, Contacts, and Calendar SQLite databases. Jocasta-mcp routes reads through this so jocasta-mcp itself doesn’t need Full Disk Access granted.
LiveKit Server	7880	com.sanctum.livekit-server	Private voice server for Yoda. Bound to Tailscale IP (100.0.0.25) only — no LAN or WAN exposure. RTC TCP companion on 7881.

Note

Kiwix requires an external T9 drive to be connected. If the drive is absent, the service will start, fail, wait 30 seconds, and try again. Forever. KeepAlive is patient. KeepAlive believes in you plugging that drive back in.

Config Example

services:
  watchdog:
    enabled: true
    settle_delay: 15
    auto_fix: true
    dedup_window: 1800
  secret_rotation:
    enabled: true
    schedule: "0 3:30 1 * *"
  icloud_filer:
    enabled: true
  kiwix:
    enabled: true
    port: 8888

VM Services

On the other side of bridge100, in a QEMU-emulated box with no internet access, lives an entirely separate operating system running its own init system with its own opinions about how services should start. A whole different world. Twelve gigabytes of RAM. Eight CPU cores. Five personalities. Zero contact with the outside world unless the Mac says so.

The VM is, in the most literal sense, a brain in a jar. An air-gapped brain in a jar that runs your haushold security agent. We thought about this. We thought about this a lot. The architecture diagram made it look intentional.

Service	Port	Codename	Systemd Unit	Description
OpenClaw Gateway	1977	Star Wars — the year hope was born	openclaw-gateway.service (user)	VM agent gateway with 1.5 GB heap. Runs 6 agents: Yoda (grand master), Mon Mothma (operations), Qui-Gon (infrastructure), Windu (security), Cilghal (health), Ki-Adi-Mundi (finance).
Docker	—	docker.service	Container runtime for any VM-side containers.
SSH	22	ssh.socket	Remote access. Key-only auth with PQ key exchange enabled.

Agent Details

Six agents. One gateway. 1.5 gigabytes of heap memory. This is either a well-orchestrated council or a timeshare dispute waiting to happen. So far, the council metaphor holds. We’ll let you know if Windu stages a coup.

Agent	Role	Specialization
Yoda	Grand Master	Senior council lead. Orchestration, council routing, final synthesis of complex decisions.
Mon Mothma	Operations	Force Flow and Living Force orchestrator. Incident correlation, boot sequences, cross-domain alignment.
Qui-Gon	Infrastructure	System health, Docker stability, automated recovery, memory triage.
Windu	Security	Security audits, Firewalla and PF rules, perimeter monitoring, daily security briefings.
Cilghal	Health	Wellness monitoring via Apple Health, cognitive profile analysis, genome-informed scaffolding.
Ki-Adi-Mundi	Finance	Triptyq Capital deal flow, personal fiscal health, expense categorization.

The gateway uses SOPS+age encryption for secrets. The sops-start.sh wrapper decrypts environment variables at startup and never writes plaintext to disk. Secrets exist in cleartext only in RAM, only while the process runs. Paranoid? Maybe. But Windu insisted, and you don’t argue with the security agent.

Note

The VM has no direct internet access. All external API calls route through Mac-side proxies or SSH tunnels. Skills sync from the Mac via rsync every 30 minutes. The VM learns about the outside world the way a medieval monk learned about distant kingdoms — through couriers, on a schedule, with a thirty-minute delay.

VM Gateway Management

# Restart the VM gateway
ssh ubuntu@10.10.10.10 'systemctl --user restart openclaw-gateway'

# Check status
ssh ubuntu@10.10.10.10 'systemctl --user status openclaw-gateway'

# View logs
ssh ubuntu@10.10.10.10 'journalctl --user -u openclaw-gateway -f'

Developer Tools

One tool. It searches markdown. That sounds trivial until you have 287 documents spread across four repositories and you’re trying to remember which file documents the port that the service you’re debugging is supposedly listening on. Then it sounds essential.

Service	Port	LaunchAgent	Description
QMD	—	—	On-device hybrid markdown search (v2.0.1). Combines BM25, vector similarity, and LLM reranking across 4 collections (287 documents). Indexes openclaw, skills, sanctum, and sanctum-docs. Exposes three MCP tools for Claude Code integration: keyword search, semantic search, and deep hybrid search. Nightly index refresh via docs-gardener. Metal-accelerated on Apple Silicon.

Note

QMD runs three small GGUF models locally — an embedding model, a reranker, and a query expansion model — totaling about 2.4 GB of cache. It has no port, no LaunchAgent, and no daemon. It indexes on demand and searches on demand. The quietest service in the stack, which is exactly what a search engine should be.

Service Lifecycle

Every service follows the same lifecycle through the configuration system. Three states: enabled, disabled, and that liminal space where you changed the YAML but forgot to regenerate the plists. We’ve all been there. The watchdog has opinions about it.

Enable

Set enabled: true in instance.yaml, run generate-plists.sh, then load the LaunchAgent:

launchctl load ~/Library/LaunchAgents/com.sanctum.service-name.plist

Disable

Set enabled: false in instance.yaml, unload the LaunchAgent, then regenerate plists:

launchctl unload ~/Library/LaunchAgents/com.sanctum.service-name.plist
~/.sanctum/generate-plists.sh

Health Check

The watchdog checks enabled services every 10 minutes. A service is considered healthy if its port responds (for port-based services) or its process is running (for background agents).

# Manual health check
sanctum_enabled openclaw_gateway && curl -sf http://localhost:1977/health

Port Summary

Every port in Sanctum has a number, and most of those numbers mean something — a movie year, a calculator joke, a cry for help. We didn’t set out to build a Deadpool-style naming convention into our network topology. It just happened, the way it always does: one engineer picks 1337 for the LLM server, another picks 42069 for the memory store, and suddenly you’re maintaining a spreadsheet of cultural references alongside your firewall rules. We leaned in. If the infrastructure is going to be absurd, it should at least be consistently absurd.

The Deadpool Protocol

Acceptable forms for a named port:

• Palindromes — 10101 reads the same backwards. The binary-21 joke is the bonus.
• Pop-culture references — a release year (1977 = Star Wars), a number from a movie (2001 = HAL), a band album (5150 = Van Halen), a sitcom unit (4077 = M*A*S*H).
• Numeric puns or math constants — 31416 ≈ π × 10⁴. The knowledge graph circles back on itself. The number earns its keep.
• Paired/sequential wit — 42069/42070: memory-vault and its reranker companion. The gag travels with the pair. One port, one joke, twice the coverage.
• Upside-down calculator — 8008. You know what you did.
• The dry acknowledgment — for defaults (8123) and sequential allocations (18080), the commentary acknowledges exactly what it is. The humor is in the honesty.

What is not acceptable: forcing a cultural reference onto a number that is just doing its job. 3030 is 3030. It is not anything else. The commentary for 3030 says “the port offers no additional commentary.” That is the commentary.

The mandate for new ports: Any PR introducing a new port must include the gag in the PR description AND add a # port_lore: <one sentence> comment to the port: field in ~/.sanctum/services/<name>.yaml. The watchdog schema ignores this comment. The next engineer at 2 AM will not. See CONTRIBUTING.md for the full checklist.

Port	Service	Host	Codename	Commentary
22	SSH	VM	—	The one port that doesn’t need a personality.
80	Dench Proxy (disabled)	Mac	Vanity Mirror	Exists solely so someone can type and feel important. Currently unplugged, like a decorative fireplace.
1111	Command Center	Mac	Make-A-Wish	11:11 — you’re supposed to close your eyes, not open a socket.
2222	Health Center	Mac	Twin Twos	The digital twin gets its own pair. Two for the body, two for the system that watches it.
1138	Voice Agent	Mac	Cell Block 1138	Reclaimed from the deprecated Neural Link, now keeping Yoda securely imprisoned in a Star Wars sandbox. Briefly drifted to LiveKit’s :8081 default during the April 2026 worker split; reclaimed once the doctrine audit caught it. THX 1138 stays.
1234	LM Studio	Mac	Password1	The port equivalent of leaving your key under the mat, except the mat is a 27-billion-parameter model.
1337	Council MLX	Mac	LEET	Because nothing says elite hacker like a Metal-accelerated language model running inference in a home office.
1969	Sonos Bridge	Mac	Woodstock	The summer of love, Hendrix, and music in every field. The Sonos bridge puts music in every room — same energy, fewer mud-covered hippies.
1977	Gateway	Mac + VM	A New Hope	Star Wars release year. The gateway between Mac and VM, which is approximately as fraught as the trench run.
1949	Sanctum Presence	Mac	Year Before Telescreens	Orwell published 1984 in 1949. The cross-session lock registry tracks who’s writing where — before any of them realize they’re being watched. Sister-port to Big Brother on 1984.
1984	Firewalla Bridge	Mac	Big Brother	George Orwell wrote a warning. We turned it into a port number for our firewall bridge. He would have had notes.
2001	Anthropic Proxy	VM	HAL	A Space Odyssey. I’m sorry, Dave, I’m afraid I can’t let you use the cloud models without a budget.
2187	Living Force (Watchdog)	Mac	Detention Block	Princess Leia’s cell number. Where we keep the watchdog that monitors all other prisoners.
2189	Sanctum Admit	Mac	Detention Block Annex	One cell over from 2187. The Capacity Doctrine controller decides who gets through the gate — admission control for heavy services before they ever touch the cellblock.
3030	Rewind Dashboard	Mac	No Additional Commentary	The canonical example from the Deadpool Protocol of a port that earns no joke — except now it carries a service. The commentary is the lack of commentary.
3100	Outline	Mac (Docker)	Page Turner	3100 — the kind of number that exists because 3000 was taken and someone started incrementing with quiet desperation.
3333	Dashboard Frontend	Mac	Quad Three	Three threes plus one more for good measure. The Vite-served front end across the wire from 1111’s backend. The slot machine pays out in auto-refresh loops.
3344	Navigator Bridge	Mac	Math Made Comfortable	33+11=44; 33×100+44=3344. Not a cultural reference — just math made comfortable. The Holocron sidecar that aggregates per-project monitor status.
3355	Tommy Guardian	Mac	Pinball Wizard	Tommy by The Who. That deaf, dumb, and blind kid sure plays a mean pinball — and the Guardian Spirit of Manoir Nepveu plays the haus by feel. Dawn and dusk patrols, no daylight.
4007	Network Control	VM	007 — Licensed to Ping	Network fabric control. The DNS manager with a license to kill NXDOMAIN. Replaces the old 18092 tunnel.
4040	Sanctum Proxy	Mac	Forty Cal	Sits at the intersection of every request that enters the haus. Named after the .40-caliber round — the proxy that guards the gate carries accordingly.
4077	Force Flow	Mac	Hawkeye	M*A*S*H 4077th — the field hospital that triaged casualties with gallows humor and a still. Force Flow triages notifications with approximately the same energy.
4078	SanctumBridge	Mac	The FDA Neighbor	One door down from Force Flow. The port that reads your messages without reading your messages — FDA-privileged proxy so the MCP server doesn’t have to be.
5150	Signal Proxy	VM	Van Halen	Eddie’s hottest album and California’s code for an involuntary psychiatric hold. Running a messaging proxy on it feels appropriate either way.
7583	signal-cli TCP	Mac	Asamk’s Default	We didn’t pick this one — signal-cli did. The streaming JSON-RPC port that the native daemon (com.sanctum.signal-cli) uses to push incoming Signal messages out to the VM-side Yoda chat consumer. The dry acknowledgment of a sane upstream default.
8008	TTS Voice	Mac	Calculator	Flip it upside down. You know what you did. Now it synthesizes speech (Qwen3-TTS via mlx-audio), which is somehow less juvenile.
8009	STT Voice	Mac	The Listener	Sequential to 8008 Calculator (TTS). The mouth and the ear, traveling as a pair — Yoda speaks on 8008, hears on 8009. The gag travels with the bundle.
8123	Home Assistant	Mac (Docker)	Default	HA’s factory port. Sometimes the most radical act is not changing the default.
8199	HA Gateway	Mac	The 81xx Neighbor	Sequential allocation in the 81xx block where the Home Assistant family clustered. The Mac-side translation gateway between Sanctum scripts and HA’s REST. No deeper joke than that — see also 8123.
8765	Yoda Orchestrator	Mac	Countdown	8‑7‑6‑5. The orchestrator that lines up STT (8009), TTS (8008), LiveKit Worker (1138), and LiveKit Server (7880) like a launch director clearing the pad.
8888	Kiwix	Mac	Lucky Eights	Four eights. Auspicious in Chinese numerology, overkill everywhere else. Houses the offline encyclopedia for when civilization gets patchy.
10101	Health Ingester	VM	Binary 21	10101 in binary is 21 — blackjack. The health ingester always hits, never stands.
18080	Orbi Bridge (HTTP)	Mac	Orbital-H	18080: HTTP’s older, more paranoid sibling who moved to a five-digit neighborhood to avoid the crowds.
18085	Orbi Bridge (API)	Mac	Orbital-A	The API counterpart to 18080. Same Orbi, different verb. REST in peace.
21063	HomeKit Bridge	Mac (Docker)	Siri’s Doorbell	Five digits of Apple-adjacent infrastructure. HomeKit wanted a port; it got the one nobody else was using.
31416	Graphiti Server	VM	Pi	3.1416 — The knowledge graph circles back on itself. Replaces the old 18093.
7880	LiveKit Server	Mac	Tailscale-Only	LiveKit’s canonical default. Bound to Tailscale IP only — what happens in the voice channel stays in the voice channel. 7881 is the RTC TCP companion.
42069	Memory Vault	Mac	Nice.	The internet’s favorite number. We put long-term memory on it because some decisions are permanent.
42070	Reranker	Mac	Nice+1.	The sequel nobody asked for but everyone needed. Jina v2 reranking on the port directly after memory-vault. The pair ships together. The gag travels with it.

Why 1977 appears on two hosts

The Gateway runs on both the Mac ( origin) and the VM ( reverse-proxied). Same port, same service, two machines — because the Rebel Alliance also operated out of multiple bases and it worked out fine until Hoth.

New arrival: 4077 — Force Flow

The newest addition to the port registry. Force Flow handles notification triage — deciding what deserves your attention and what gets filed under the haus is fine, stop asking. We gave it 4077 because, like the 4077th M*A*S*H, it operates in a permanent state of controlled chaos, sorting the critical from the cosmetic while maintaining a dark sense of humor about the whole situation. Hawkeye Pierce would approve of a system that intercepts alerts about your thermostat with the same gravity as a push notification about your front door.
