Config System

Sanctum follows a single-source-of-truth principle: one YAML file defines the entire instance. Every service, script, dashboard, and LaunchAgent reads its configuration from this file — either directly or through generated artifacts. Secrets are stored separately in macOS Keychain and never appear in configuration files.

This is either an act of elegant simplicity or a magnificent dare. One file. One indentation error away from a very quiet haus.

Configuration Hierarchy

🔍 Hover to zoom

Everything flows down from that YAML file at the top. If you’re looking for the single point of failure, you found it. If you’re looking for the single source of truth, you also found it. Schrodinger’s architecture decision: genius and catastrophe in the same file, and you won’t know which until you open it.

instance.yaml

The central configuration file lives at ~/.sanctum/instance.yaml. It contains every instance-specific value: network addresses, service ports, node definitions, feature flags, and integration settings.

~/.sanctum/instance.yaml

instance:
  name: Manoir Neo
  slug: manoir-neo
  timezone: America/New_York

network:
  mac_bridge_ip: 10.0.0.1
  vm_ip: 10.0.0.10
  mac_lan_ip: 192.0.2.10
  bridge_subnet: 10.0.0.0/24
  lan_subnet: 192.0.2.0/24

services:
  home_assistant:
    port: 8123
    homekit_port: 21063
  dashboard:
    port: 3333
    backend_port: 1111
  council_mlx:
    enabled: true
    port: 1337                          # sanctum-mlx serving Qwen3.6-35B-A3B-4bit (mTLS)
    model_path: ~/Projects/mlx-finetune/models/Qwen3.6-35B-A3B-4bit-text
  voice_agent:
    enabled: true
    port: 1138
  # ... additional services

# The coder seat (Codestral-22B at :3301) is NOT a services.* block --
# it's a router backend. The router owns where prompts get sent:
router:
  backends:
    coder:
      url: http://127.0.0.1:3301/v1   # sanctum-mlx-codestral, plain HTTP
      default_model: mlx-community/Codestral-22B-v0.1-4bit

nodes:
  hub:
    type: hub
    host: 192.0.2.10
    tailscale_ip: 100.0.0.20
    ssh_user: operator
    services: [home_assistant, dashboard, voice_agent, council_mlx]
  satellite:
    type: satellite
    host: null  # set during on-site install
    tailscale_ip: 100.0.0.30
    ssh_user: operator
    services: [home_assistant]

Tip

An annotated example file is available at ~/.sanctum/instance.yaml.example. Copy it as your starting point when creating a new instance. Read it slowly. The comments are trying to save you from the mistakes we already made.

JSON Cache

The JSON cache at ~/.sanctum/.instance.json is an auto-generated derivative of the YAML file. It exists so that shell scripts and lightweight tools can parse configuration without a YAML library.

# Regenerate the cache manually (normally automatic)
python3 ~/.sanctum/lib/yaml2json.py

The cache is regenerated automatically whenever configuration libraries detect the YAML file is newer than the JSON. Never edit .instance.json by hand — changes will be overwritten. This is not a suggestion. The file is named with a dot prefix for a reason. It is trying to hide from you.

Shell Library

Source config.sh in any Bash script to get access to configuration values:

source ~/.sanctum/lib/config.sh

Available Functions

Function	Description	Example
sanctum_get <path>	Read a value by dotted path	sanctum_get services.voice_agent.port
sanctum_slug	Return the instance slug	manoir-neo
sanctum_home	Return the Mac home directory	/Users/neo
sanctum_vm_ssh	Return the VM SSH target	ubuntu@10.0.0.10
sanctum_enabled <service>	Check if a service is enabled	sanctum_enabled voice_agent
sanctum_expand <template>	Expand {{PLACEHOLDER}} strings	See below
sanctum_whoami	Return this node’s identity	hub
sanctum_node_ts_ip <node>	Read a typed field from a node	sanctum_node_ts_ip satellite

There’s a typed helper for each node field that gets read often — sanctum_node_type, sanctum_node_host, sanctum_node_user, sanctum_node_ts_ip — so you’re not reaching for sanctum_get nodes.X.field every time. They’re thin wrappers around exactly that, named so the call site reads like a sentence.

Usage Example

#!/bin/bash
source ~/.sanctum/lib/config.sh

if sanctum_enabled voice_agent; then
  PORT=$(sanctum_get services.voice_agent.port)
  echo "Voice agent running on port $PORT"
fi

VM=$(sanctum_vm_ssh)
ssh "$VM" 'systemctl --user status openclaw-gateway'

TypeScript Library

The TypeScript library provides the same capabilities for Node.js services like the command center dashboard and gateway plugins.

import { get, isEnabled, expand, vmSsh, whoami, nodeGet, getNodesByType } from './lib/config';

Available Functions

Function	Description	Return Type
get(path)	Read a value by dotted path	string | number | boolean | object
isEnabled(service)	Check if a service is enabled	boolean
expand(template)	Replace {{PLACEHOLDER}} tokens	string
vmSsh()	Return the VM SSH connection string	string
whoami()	Return this node’s identity	string
nodeGet(node, field)	Read a value from a specific node	T (defaults to string)
getNodesByType(type)	List nodes of a given type	Array<{ id: string } & object>

Usage Example

import { get, isEnabled } from './lib/config';

const port = get('services.dashboard.port') as number;  // 3333

if (isEnabled('home_assistant')) {
  const haPort = get('services.home_assistant.port');  // 8123
  console.log(`HA available at http://localhost:${haPort}`);
}

Note

The dashboard serves the instance configuration (with secrets excluded) at the /api/config endpoint for client-side components.

Plist Templates

LaunchAgent plist files are generated from templates rather than hand-maintained. This ensures every plist stays in sync with instance.yaml and that secrets are injected at generation time from macOS Keychain.

If you’ve ever manually edited 11 plist files, changed a port number, missed one, and then spent 45 minutes watching logs from the wrong service — this system exists because of you. Well. Because of us.

Templates live in ~/.sanctum/templates/launchagents/ and use a {{PLACEHOLDER}} syntax:

<!-- Template: com.sanctum.council-mlx.plist -->
<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN"
  "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
<plist version="1.0">
<dict>
    <key>Label</key>
    <string>com.sanctum.council-mlx</string>
    <key>ProgramArguments</key>
    <array>
        <string>{{MAC_HOME}}/.sanctum/bin/sanctum-council-mlx</string>
        <string>--model</string>
        <string>{{MLX_MODEL_PATH}}</string>
        <string>--host</string>
        <string>{{MAC_BRIDGE_IP}}</string>
        <string>--port</string>
        <string>{{MLX_PORT}}</string>
    </array>
    <key>StandardOutPath</key>
    <string>{{LOGS_DIR}}/mlx-server.log</string>
    <key>RunAtLoad</key>
    <true/>
    <key>KeepAlive</key>
    <true/>
</dict>
</plist>

Generating Plists

The generate-plists.sh script renders all templates:

1. Reads instance.yaml for service ports, paths, and feature flags.
2. Pulls tokens from macOS Keychain (e.g., GATEWAY_TOKEN).
3. Skips templates for disabled services (enabled: false).
4. Writes rendered plists to ~/Library/LaunchAgents/.

# Preview what would be generated
~/.sanctum/generate-plists.sh --dry-run

# Generate and install all plists
~/.sanctum/generate-plists.sh

Caution

After regenerating plists, you must launchctl unload and launchctl load any changed agents for the new configuration to take effect. The watchdog will detect stopped services and restart them if needed. launchctl does not care about your feelings or your intention to restart things “in a minute.”

Secrets Management

Secrets never appear in instance.yaml or any configuration file. They live in two stores, split by what they protect: per-service tokens in the Keychain, the gateway config under SOPS.

macOS (Keychain)

Tokens and API keys are stored in the macOS login Keychain. The plist generator and shell scripts retrieve them using the security command:

security find-generic-password -a "sanctum" -s "gateway-token" -w

Secrets are rotated monthly by the com.sanctum.rotate-secrets LaunchAgent, which runs on the 1st of each month at 3:30 AM. Nothing like waking up to fresh tokens you didn’t have to think about.

Gateway (SOPS + age)

The OpenClaw gateway config is encrypted at rest with SOPS and age. The encrypted file is the source of truth and lives in git; the plaintext is regenerated on every launch and never committed:

# Encrypted source of truth (git-tracked)
~/.openclaw/openclaw.json.enc

# Decrypt wrapper, wired into ai.openclaw.gateway as ProgramArguments[0]
~/.openclaw/scripts/sops-start.sh

# age private key (never leaves the host)
~/.config/sops/age/keys.txt

At launch, sops-start.sh decrypts openclaw.json.enc into openclaw.json (mode 0600, gitignored), then execs SanctumBridge. One guardrail worth knowing: if you edit openclaw.json directly and it’s newer than the encrypted source, the wrapper skips the decrypt rather than clobber your edits — and quietly reminds you to re-encrypt. The plaintext is disposable; the .enc is the one you protect.

Danger

Never commit secrets to Git, never add them to instance.yaml, and never pass them as command-line arguments (they appear in ps output). Keychain holds the per-service tokens; SOPS + age holds the gateway config. If you’re reading this because you already did one of those things — rotate immediately. We’ll wait.

Adding a New Service

To add a new service to the configuration layer:

1. Add a services.<name> block to instance.yaml with at least enabled and port.
2. If the service needs a LaunchAgent, create a template in templates/launchagents/.
3. If the service needs secrets, store them in Keychain and reference them as {{PLACEHOLDER}} in the template.
4. Run generate-plists.sh to render the new plist.
5. Add the service to the appropriate node’s services list in instance.yaml.
6. Update the watchdog configuration if the service should be health-checked.

Note

Six steps. That’s not bad for a system that will now automatically start, monitor, restart, and health-check your new service across reboots and power failures. You’ve traded six steps for never thinking about it again. That’s the deal.
