Signal CLI API Reference

Sanctum runs three separate Signal interfaces. They share a name and a purpose but almost nothing else. Confusing them is the most common source of 404 errors in the stack, because “signal-cli on port 8080” and “signal-cli on port 18081” are not the same service, the same protocol, or the same API. They are three strangers with the same surname who happen to live in the same building.

The Three Interfaces

Interface	Port	Protocol	Container / Process	API Style
signal-cli native	8080	JSON-RPC	Homebrew binary (PID on Mac)	POST /api/v1/rpc
signal-cli-rest-api	18081	REST	Docker: signal-cli-rest-api	/v1/..., /v2/...
signal-yoda	18082	REST	Docker: signal-yoda	/v1/..., /v2/...

Danger

Port 8080 does not serve REST endpoints. Hitting /v1/about or /api/v1/accounts on port 8080 will always return 404 Not Found with No context found for request. This is not a bug. The native --http mode only speaks JSON-RPC. The REST endpoints live on ports 18081 and 18082 via the bbernhard Docker wrapper.

1. signal-cli Native (Port 8080)

The Homebrew-installed signal-cli 0.14.2 binary running as a daemon with --http 127.0.0.1:8080. This is OpenClaw’s primary bridge — Yoda sends and receives messages through this interface.

Process: signal-cli -a +1XXXXXXXXXX daemon --http 127.0.0.1:8080 --no-receive-stdout

Endpoints

Method	Path	Description
POST	/api/v1/rpc	JSON-RPC 2.0 endpoint (the only real endpoint)
GET	/api/v1/events	Server-Sent Events stream for incoming messages
GET	/api/v1/check	Health check

Everything else returns 404. There is no /v1/about. There is no /api/v1/accounts. Those paths belong to the Docker wrapper, not this interface.

JSON-RPC Examples

Send a message:

curl -s -X POST -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","method":"send","params":{"recipient":["+1XXXXXXXXXX"],"message":"Hello from Sanctum"},"id":1}' \
  http://127.0.0.1:8080/api/v1/rpc

Get version:

curl -s -X POST -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","method":"version","id":2}' \
  http://127.0.0.1:8080/api/v1/rpc
# Returns: {"jsonrpc":"2.0","result":{"version":"0.14.2"},"id":2}

List groups:

curl -s -X POST -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","method":"listGroups","id":3}' \
  http://127.0.0.1:8080/api/v1/rpc

Check if a number is registered:

curl -s -X POST -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","method":"getUserStatus","params":{"recipient":["+1XXXXXXXXXX"]},"id":4}' \
  http://127.0.0.1:8080/api/v1/rpc

Available JSON-RPC Methods

Key methods (camelCase, passed as "method" in the JSON-RPC request): send, sendReceipt, listGroups, updateGroup, getUserStatus, version, sendSyncRequest, listContacts, block, unblock, startLink, finishLink, subscribeReceive, unsubscribeReceive.

Full method list: signal-cli-jsonrpc(5) man page.

2. signal-cli-rest-api (Port 18081)

The bbernhard/signal-cli-rest-api Docker wrapper. Provides a proper REST API with versioned endpoints. Runs its own signal-cli instance internally with a separate data directory (data-rest-api/).

Container: signal-cli-rest-api on 127.0.0.1:18081

Key REST Endpoints

Method	Path	Description
GET	/v1/about	Version info, capabilities, mode
GET	/v1/accounts	List registered accounts
POST	/v2/send	Send a message (v2 — supports quotes, mentions)
GET	/v1/groups/{number}	List groups for an account
GET	/v1/receive/{number}	Receive pending messages

REST Example

# Check version
curl -s http://127.0.0.1:18081/v1/about
# Returns: {"versions":["v1","v2"],"build":2,"mode":"json-rpc","version":"0.98",...}

# Send a message
curl -s -X POST -H "Content-Type: application/json" \
  -d '{"message":"Hello","number":"+1XXXXXXXXXX","recipients":["+1XXXXXXXXXX"]}' \
  http://127.0.0.1:18082/v2/send

3. signal-yoda (Port 18082)

Identical to the REST API above but with a separate data directory (data-yoda/). This is the Yoda-specific Signal identity used by the agent council. Same image, same API, different account.

Container: signal-yoda on 127.0.0.1:18082

Docker Compose

Both Docker containers are defined in ~/.openclaw/signal-cli/compose.yaml:

services:
  signal-cli-rest-api:
    image: bbernhard/signal-cli-rest-api:latest
    container_name: signal-cli-rest-api
    restart: unless-stopped
    environment:
      - MODE=json-rpc
    ports:
      - "127.0.0.1:18081:8080"
      - "127.0.0.1:6001:6001"
    volumes:
      - ./data-rest-api:/home/.local/share/signal-cli

  signal-cli-yoda:
    image: bbernhard/signal-cli-rest-api:latest
    container_name: signal-yoda
    restart: unless-stopped
    environment:
      - MODE=json-rpc
    ports:
      - "127.0.0.1:18082:8080"
      - "127.0.0.1:6002:6001"
    volumes:
      - ./data-yoda:/home/.local/share/signal-cli

Docker Compose container naming bug

Docker Compose v5 has a known issue where stale container references corrupt the project state. If docker compose up fails with Error response from daemon: No such container: <hash>, the fix is: stop and remove all signal containers manually, then recreate the yoda container with docker run using the exact same flags from the compose file. The compose state for the yoda service gets stuck referencing a deleted container ID and no amount of docker compose down will clear it.

OpenClaw Integration

OpenClaw connects to signal-cli via the native CLI binary, not through any HTTP API. The relevant config in openclaw.json:

{
  "channels": {
    "signal": {
      "accounts": {
        "yoda": {
          "name": "Yoda Signal",
          "enabled": true,
          "account": "+1XXXXXXXXXX",
          "cliPath": "/opt/homebrew/bin/signal-cli"
        }
      },
      "enabled": true
    }
  }
}

This means OpenClaw messaging works even when the HTTP/REST interfaces are down. The CLI binary talks directly to the signal-cli daemon via its internal socket, not via HTTP. The HTTP API is for external tooling, health checks, and regression tests — not for the primary message flow.

Quick Diagnostic

# Native JSON-RPC (should return version)
curl -s -X POST -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","method":"version","id":1}' \
  http://127.0.0.1:8080/api/v1/rpc

# REST API container 1 (should return about info)
curl -s http://127.0.0.1:18081/v1/about

# REST API container 2 / Yoda (should return about info)
curl -s http://127.0.0.1:18082/v1/about

# Docker container status (both should be "running")
docker inspect --format '{{.State.Status}}' signal-cli-rest-api signal-yoda

Health Monitoring

The signal-health.sh script provides military-grade monitoring of all Signal interfaces with auto-recovery capabilities.

Location: ~/.sanctum/scripts/signal-health.sh

Usage

# Check-only mode (human-readable)
~/.sanctum/scripts/signal-health.sh

# Auto-fix mode (restarts failed components)
~/.sanctum/scripts/signal-health.sh --fix

# Machine-readable JSON output
~/.sanctum/scripts/signal-health.sh --json

# Silent mode (log only, no stdout)
~/.sanctum/scripts/signal-health.sh --fix --quiet

What It Checks

Component	Check	Auto-Fix Action
Native daemon (:8080)	JSON-RPC version call	Restart via launchctl or direct launch
signal-cli-rest-api (:18081)	/v1/accounts returns expected account	docker restart signal-cli-rest-api
signal-yoda (:18082)	/v1/accounts returns Yoda number	docker restart signal-yoda
OpenClaw bridge (:1977)	Gateway listening + node bridge connected to :8080	Report only (manual)

Exit Codes

Code	Meaning
0	All components healthy
1	One or more components were down but auto-recovered
2	Manual intervention required

LaunchAgent (Periodic Monitoring)

A LaunchAgent runs the health check every 5 minutes with --fix --quiet:

Plist: ~/Library/LaunchAgents/com.sanctum.signal-health.plist

# Check status
launchctl list | grep signal-health

# Reload after edits
launchctl unload ~/Library/LaunchAgents/com.sanctum.signal-health.plist
launchctl load ~/Library/LaunchAgents/com.sanctum.signal-health.plist

Logs

All health check results are appended to ~/.sanctum/logs/signal-health.log. LaunchAgent stdout/stderr go to ~/.sanctum/logs/signal-health-stdout.log and signal-health-stderr.log.

Architecture Notes

Tip

The 18081 container (signal-cli-rest-api) runs account +15555550101 — a different number from Yoda. The Yoda account (+15555550100) lives on the native daemon (:8080) and the signal-yoda container (:18082). Trying to send as Yoda via :18081 will always return “Specified account does not exist” — this is expected behavior, not a bug.
