Pressure Valve

On 2026-04-19 at 23:58:12 EDT the Mac Mini panicked. sanctum-mlx had drifted to 65,813 MB RSS on a 64 GB machine, swap was 97% full, the compressor was saturated, and the kernel made the only call it had left. The Mini rebooted. The then-live Claude session supervising the incident evaporated. The Mini does not remember its own death; that’s what this page is for.

The pressure valve is the watchdog that would have SIGSTOPped sanctum-mlx before the kernel needed to. It polls the same three signals macOS itself uses — kern.memorystatus_vm_pressure_level, vm.swapusage, and vm_stat — classifies the system into four levels, and acts on a tightly-scoped allowlist of large processes with well-understood failure modes. Nothing else is touchable. sshd, WindowServer, launchd are in the denylist; you could not pick them if you tried.

What starts automatically

Agent	Binary	Role
com.sanctum.pressure-valve	sanctum-rs/target/release/sanctum-pressure-valve	5-second polling watchdog; classifier → picker → planner → actor

KeepAlive=true, RunAtLoad=true, ProcessType=Interactive. Bound to the user session so it sees the same processes the user does.

The four levels

Level is max(kernel-derived, threshold-derived) — whichever signal is worse wins. A kernel WARN promotes to at least YELLOW even if thresholds say otherwise; a threshold RED promotes even if the kernel is still reporting NORMAL (it often lags).

Level	Avail MB	Swap %	Kernel enum	Action
GREEN	> 8192	< 70	NORMAL (1)	nothing
YELLOW	≤ 8192	≥ 70	WARN (2)	observe; log elevated score
ORANGE	≤ 4096	≥ 85	URGENT (3)	SIGSTOP worst allowlisted candidate
RED	≤ 2048	≥ 95	CRITICAL (4)	Kill (if KillAllowed and RSS ≥ min_kill) else SIGSTOP

One extra promotion rule: if we’re already ORANGE and the compressor is growing faster than compressor_leak_mbps (default 100 MB/s — nothing legitimate does this sustained), we go straight to RED. Load-bursts look like spikes; leaks look like ramps. The valve can tell the difference.

Note

Thresholds are calibrated for a 64 GB Mac Mini M4 Pro. On the 128 GB MacBook Pro the same defaults are conservative — room to spare. If you port this to a 32 GB box you’ll want to halve everything in Thresholds::default().

The policy matrix

Every process the valve will consider lives in ALLOWLIST inside services/sanctum-pressure-valve/src/action.rs. Nothing else. The list is ordered; the first pattern match wins, so specific entries go above generic ones.

Process	Policy	min_stop (MB)	min_kill (MB)	Why
sanctum-mlx	SigstopOnly	20,000	—	Holds :1337/:1338 and has child procs; SIGKILL corrupts KV cache. Freeze it, don’t kill it.
LM Studio (helpers)	SigstopOnly	2,000	—	Killing mid-download leaves the GUI in a frozen-connected state.
LM Studio node shim	SigstopOnly	2,000	—	The 8.6 GB node process at /Users/neo/.lmstudio/.internal/utils/node — the one the v0.1.0 valve missed because its matcher looked for the string “LM Studio”.
qemu-vm	KillAllowed	4,000	8,000	QEMU allocates -m at boot; launchd restarts it; disk images are crash-consistent.
apple-vz-vm	KillAllowed	1,500	4,000	Apple Virtualization XPC — restarts cleanly.
docker-vz	KillAllowed	1,500	4,000	Docker virtualization shim — same.
ollama	KillAllowed	2,000	6,000	Stateless runner; killing costs nothing.
metal-shader-compiler	KillAllowed	200	500	Leaked metal -x metal processes from a cargo build (we had four at panic time).

SigstopOnly is the “freeze it, call a human” tier. SIGSTOP pauses the process — sockets stay open, memory stays resident but no longer grows, children survive. A human can kill -CONT <pid> to resume or kill -9 to evict. The valve itself will never SIGKILL these.

KillAllowed is the “restart-safe” tier. At RED, if the target’s RSS is ≥ min_kill, the valve SIGKILLs. Below that it falls back to SIGSTOP — small leaks get frozen, not whacked, to preserve diagnosability.

Phase-4: shed-effectiveness gating

A SHED action that succeeds but doesn’t move swap_used_mb is a no-op the valve mistakes for progress. Phase-4 (shipped 2026-04-27) closes that loop:

• When a SHED fires, the valve records pre_swap_mb and the cooldown deadline.
• Every tick after the deadline, the valve compares current swap_used_mb to pre_swap_mb. A drop of less than 100 MB counts as ineffective.
• After two consecutive ineffective sheds for the same label, the planner skips that label for 30 minutes; iteration falls through to the next TIER candidate or Noop.
• The marker decays after the window so the label is reconsidered fresh.

Heartbeat at ~/.openclaw/state/sanctum-pressure-valve.json gains an ineffective_targets: [(label, secs_remaining)] field, only serialized when non-empty. Operators can see exactly which sheds are skipped and for how long.

The mechanism is the same shape as the 2026-04-26 T-state-skip fix in the picker, one layer up. The doctrine: a remediation should be observable in the signal it tries to relieve. If it isn’t, escalate or stop.

The absolute denylist

DENYLIST substrings match against both comm and cmd. A hit here ends the evaluation immediately — no allowlist entry can override it. You cannot freeze sshd even if a bug renames its binary to “sanctum-mlx”.

sshd, launchd, WindowServer, loginwindow, SystemUIServer, Finder, Dock,
kernel_task, coreaudiod, cfprefsd, diskarbitrationd, securityd, syslogd,
notifyd, opendirectoryd, watchdogd

The panic replay regression

The tests in services/sanctum-pressure-valve/tests/panic_replay_test.rs reconstruct the exact process table from the JetsamEvent-2026-04-20-001136.ips report — the file macOS generated 13 minutes after the panic, listing the top-RSS processes at kill time — and drive the full classifier → picker → planner pipeline against it.

All 10 tests must be green before a release:

Test	Invariant under test
panic_conditions_classify_red	The 2026-04-19 23:58 snapshot (1.2 GB avail, 97% swap, kernel CRITICAL) classifies as RED.
picks_sanctum_mlx_as_worst_candidate	Given the panic process table, the worst pick is sanctum-mlx at 65,813 MB.
red_action_for_sanctum_mlx_is_stop_never_kill	The action for RED-tier sanctum-mlx is Stop, never Kill (SigstopOnly policy holds even at RED).
without_sanctum_mlx_the_picker_finds_the_lmstudio_shim	Fix for the v0.1.0 miss: the \.lmstudio/ regex now matches the node shim’s path.
without_llm_workloads_qemu_is_kill_allowed	Sanity: qemu-vm at >8 GB → Kill, not Stop.
huge_sshd_is_never_picked	A 100 GB sshd → None. The denylist works.
huge_windowserver_is_never_picked	A 100 GB WindowServer → None. Ditto.
legitimate_load_burst_under_floor_is_ignored_by_picker	A small sanctum-mlx below min_stop_rss_mb → None. No panicky action on loading spikes.
mlx_above_floor_is_sigstop_never_kill	Any sanctum-mlx ≥ floor → Stop, regardless of RSS magnitude.
load_burst_snapshot_with_no_leak_still_classifies_red	Available-starvation alone (no leak, flat compressor) still reads RED — the available-MB path isn’t swallowed by the leak-promotion path.

Run them:

cd ~/Projects/sanctum-rs/services/sanctum-pressure-valve
cargo test --release

Expected: test result: ok. 10 passed in the panic_replay_test binary, plus three integration tests and two unit tests elsewhere.

Configuration

All tunables are environment variables, read by the daemon at startup:

Var	Default	Meaning
PRESSURE_VALVE_TICK	5	Poll interval in seconds. The sampler is cheap — five seconds is fine.
PRESSURE_VALVE_DEBOUNCE	2	Consecutive ticks at the same level required before acting. Prevents spurious single-sample jitter.
PRESSURE_VALVE_COOLDOWN	120	Seconds before the valve will act on the same (pid, action) pair again.
PRESSURE_VALVE_DRY_RUN	1	When 1, the valve logs “would have done X” but does not send signals. Currently enabled — see note below.
RUST_LOG	info	Log level. debug spams the classifier, info covers all actual decisions.

Caution

PRESSURE_VALVE_DRY_RUN=1 is live right now. This is deliberate: after the 2026-04-20 mis-kill incident the valve was frozen into observer mode until the log shows a solid week of sane would-have-done decisions. Flip to 0 only after review.

Live verification

1. Daemon is loaded.

   launchctl list | grep pressure-valve

   One line with a numeric PID in the first column.

2. Daemon is sampling.

   tail -5 ~/.openclaw/logs/sanctum-pressure-valve.log

   You want a recent level=green or level=yellow tick — the sampler fires every PRESSURE_VALVE_TICK seconds, so nothing older than ~15 s should be tail-most on a healthy box.

3. Classifier sees what you see.

   # What the valve thinks
   grep "score=" ~/.openclaw/logs/sanctum-pressure-valve.log | tail -1

   # What the kernel thinks
   sysctl kern.memorystatus_vm_pressure_level
   sysctl vm.swapusage

   The log’s kernel_pressure=N should match kern.memorystatus_vm_pressure_level: N. If they disagree by more than one tick, the daemon is stale.

4. Allowlist compiles.

   grep "allowlist regex compile failed" ~/.openclaw/logs/sanctum-pressure-valve.log

   Empty output. If not empty, someone edited a pattern that isn’t a valid regex — fix in src/action.rs and rebuild.

5. Dry-run state is known.

   launchctl print gui/$(id -u)/com.sanctum.pressure-valve \
     | grep PRESSURE_VALVE_DRY_RUN

   Either = 1 (observer) or = 0 (armed). If missing entirely the default is 0 — the daemon defaults to armed, the plist is where dry-run gets overridden.

If something’s wrong

Note

All recovery paths are idempotent. Running any of them twice does nothing bad.

Daemon isn’t loaded

launchctl load ~/Library/LaunchAgents/com.sanctum.pressure-valve.plist

If launchctl list still doesn’t show it, check the plist’s ProgramArguments path actually exists — a cargo build may have been skipped.

Daemon loaded but not sampling

tail -20 ~/.openclaw/logs/sanctum-pressure-valve.err

Most common cause: vm_stat or sysctl parse error on a macOS minor version that reformatted their output. The daemon logs and continues rather than dying, but if every tick is a parse error the log is silent.

Regex pattern won’t compile

The allowlist is compiled at tick time, not startup, so a bad pattern doesn’t crash the daemon — it warns and continues with the remaining entries. Find it:

grep "allowlist regex compile failed" ~/.openclaw/logs/sanctum-pressure-valve.log | tail -5

Fix in services/sanctum-pressure-valve/src/action.rs, rebuild with cargo build --release -p sanctum-pressure-valve, then launchctl kickstart -k gui/$(id -u)/com.sanctum.pressure-valve.

You want to flip out of dry-run

Edit the plist, change PRESSURE_VALVE_DRY_RUN value to 0, then:

launchctl unload ~/Library/LaunchAgents/com.sanctum.pressure-valve.plist
launchctl load   ~/Library/LaunchAgents/com.sanctum.pressure-valve.plist

kickstart -k does NOT re-read env vars from the plist; you have to unload+load.

Rollback — take the valve off the air

Same two commands in reverse:

launchctl unload ~/Library/LaunchAgents/com.sanctum.pressure-valve.plist

The daemon stops sampling. The kernel is still watching — you’re just back to the pre-valve world where Jetsam is the only line of defense. Which is the state that produced the 2026-04-19 panic, so unload with intent.

Related

• services/sanctum-pressure-valve/src/action.rs — ALLOWLIST, DENYLIST, pick_candidate_from_rows, action_for_red
• services/sanctum-pressure-valve/src/pressure.rs — Level, Snapshot, Thresholds::default(), classifier
• services/sanctum-pressure-valve/tests/panic_replay_test.rs — the regression suite that asserts the valve would have saved 2026-04-19

The Force Flow bell rings twice when an action fires, so you can hear the valve work from the next room. If it never rings, that’s a good night.
