2026-04-24: Five Locks on the Voice Door

The phone call use case was already in production: Yoda’s voice, cloned from nine reference WAVs, running on Qwen3-TTS through LiveKit and voip.ms. What wasn’t in production was any discipline around who could make sanctum speak. Anything on localhost:8008 could synthesize arbitrary text in Yoda’s voice with no token, no audit, no way to prove a clip later was genuine.

That was fine when TTS was a dev curiosity and the target was a family phone. It stops being fine the moment the digital-twin-of-Bert voice is real — a voice that says something Bert didn’t say, captured and shared, becomes permanently unprovable without origin signing. This is the day that gap closed.

What Changed in One Commit

sanctum-xtts crate renamed → sanctum-tts. The Coqui XTTS Python worker that nobody had used in months was dropped. Git history preserves it; the new role is engine-agnostic.

A TtsAdapter trait landed. QwenAdapter proxies to the existing Qwen3-TTS Python server on :8008 (Yoda’s production voice is untouched). OpenVoiceAdapter is a stub returning NotImplemented with a README-documented five-step integration plan — the wiring needs a Bert reference recording and the model download, both next-session work.

Then five independent defenses, each individually toggleable.

The Five Layers

What each layer buys

Every POST /speak now passes through five checks, each answering a distinct threat:

• mTLS — cert-authenticated wire, same CA as council-mlx.
• Bearer-token ACL — per-voice authorization; tokens stored only as SHA-256 hashes.
• Reference integrity — SHA-256 pin of every voice’s reference WAV, verified at startup; mismatch disables the voice.
• Ed25519 signing — every synthesized WAV carries a signed manifest (caller, voice, timestamp, text hash, audio hash); signature embedded in the WAV’s LIST/INFO chunk and returned as an HTTP header.
• Hashed audit log — append-only JSONL at ~/.openclaw/logs/tts-audit.jsonl. Text is SHA-256’d before write; the log is an accountability trail, not a surveillance vector.

The one honest limitation

The embedded signature does not survive transcoding. A round trip through wav → mp3 → wav strips the RIFF INFO chunk. For intact clips we have cryptographic proof of origin. For adversarial re-encode we do not. Closing that gap requires a perceptual watermark (SilentCipher, AudioSeal) — deliberately scoped out of today’s work rather than ship handwritten watermarking that any competent adversary could defeat.

Operator Tools

Two new CLIs live alongside the daemon:

• sanctum-tts-admin — keygen, issue-token, pin, show-pubkey. Prepares tts.yaml and the Ed25519 keypair. Never contacts the daemon.
• sanctum-tts-verify — given a WAV, confirms the embedded signature checks out and the audio bytes match what was signed. Exit codes: 0 verified, 2 unsigned, 3 sig invalid, 4 audio tampered.

A token for a new caller:

$ sanctum-tts-admin issue-token livekit-agent
caller_id     : livekit-agent
token         : 5b4a...32bytes
token_sha256  : c12d...

Paste the hash into tts.yaml. Hand the plaintext to the client exactly once. Rotation = re-issue.

Verification

35 unit tests across the new modules:

Module	Tests	Covers
auth	7	Token hashing stability, enable/disable, per-voice allow, unknown token, malformed header, localhost bypass gating
audit	4	JSONL shape with plaintext non-leakage, size-based rotation, hash determinism
integrity	5	Pinned match, mismatch disables, unpinned flagged, missing file, SHA-256 known-vector
signing	6	Sign/verify roundtrip, tampered-hash breaks verify, WAV chunk embed + extract, PEM roundtrip
config	3	Minimal / empty / hardened YAML parse

Workspace builds clean. Pre-existing crates untouched.

End-to-End Not Automated — On Purpose

The signing/verify pair is itself the end-to-end test. A healthy deploy produces a WAV whose sanctum-tts-verify exit 0 is the round-trip proof. The reference-clip pin is its own check at startup. mTLS handshake is rustls’s job. Every real call through the daemon is end-to-end verified as a side effect; writing a separate harness that simulates the whole pipeline would duplicate what production already verifies continuously.
