Home Assistant Integration

Home Assistant is Sanctum’s haus automation hub. It runs as a Docker container on the Mac Mini with host networking under OrbStack, integrating HomeKit devices and providing remote access through a Cloudflare tunnel. Sonos speakers are managed by a separate native bridge running directly on the Mac, because Docker bridge networking and Sonos callbacks have a relationship best described as “irreconcilable differences.”

Architecture

┌────────────────────────────────────────────────┐
│ Mac Mini                                       │
│                                                │
│  ┌──────────────────────────────────────────┐  │
│  │ Sonos Bridge (native, port 1969)         │  │
│  │  SoCo → SSDP → 10 Sonos speakers         │  │
│  │  Qwen3-TTS → port 8008 → Yoda voice      │  │
│  └────────────┬─────────────────────────────┘  │
│               │ REST (host.docker.internal)    │
│  ┌────────────▼─────────────────────────────┐  │
│  │ Docker / OrbStack (host networking)      │  │
│  │                                          │  │
│  │   ┌──────────────────────────────────┐   │  │
│  │   │ Home Assistant Container         │   │  │
│  │   │  Port 8123 → Web UI              │   │  │
│  │   │  Port 21063 → HomeKit Bridge     │   │  │
│  │   │  SSH agent → VM access           │   │  │
│  │   └──────────────────────────────────┘   │  │
│  └──────────────────────────────────────────┘  │
│                                                │
│  Cloudflare Tunnel → ha.example.net            │
└────────────────────────────────────────────────┘

HA moved from the VM to Mac Docker because SLIRP networking couldn’t keep up with this many integrations and real-time device traffic. Sonos was later pulled out of HA entirely because Docker networking on macOS couldn’t reliably hold the bidirectional callback connection Sonos demands. Two migrations, two networking problems, one closet.

Docker Configuration

The container uses network_mode: host. On macOS that was the impossible setting for years — Docker Desktop runs containers inside a Linux VM, so “host networking” meant the VM’s host, not the Mac’s. OrbStack is the runtime that actually delivers it: the container shares the Mac’s real network stack, which is the whole reason it can see the mDNS and SSDP broadcasts that HomeKit and Sonos discovery depend on.

Key Settings

Setting	Value
Image	ghcr.io/home-assistant/home-assistant:stable
Network mode	host (network_mode: host)
Web UI port	8123
HomeKit port	21063
Config directory	~/.openclaw/homeassistant/
Restart policy	unless-stopped

Compose File

The compose.yaml at ~/.openclaw/homeassistant/ defines the container with these essential directives:

• Network mode: host — no ports: block, because there’s no NAT to traverse. 8123 and 21063 bind straight to the Mac.
• Volume mount: Local config directory into /config
• cap_add: NET_RAW: lets the container send the raw mDNS/SSDP packets discovery relies on
• Extra hosts: host.docker.internal:host-gateway for reaching Mac-native services (like the Sonos Bridge) from inside the container
• SSH agent socket: /run/host-services/ssh-auth.sock mounted for agent forwarding to the VM

Runtime: OrbStack, not Docker Desktop

Docker Desktop on macOS runs a Linux VM and tells you --network=host means host networking. It does not — it means the VM’s network, a thing that cannot see mDNS broadcasts and so cannot discover the Ecobee thermostats HA’s HomeKit Controller finds via Bonjour. Docker Desktop was first swapped for Colima, then Colima for OrbStack on April 27, 2026 (Colima’s SSH ControlMaster bug wedged the daemon one too many times). OrbStack gives containers the Mac’s real network stack — true host networking, no VM seam. Its socket:

DOCKER_HOST=unix:///Users/neo/.orbstack/run/docker.sock

The startup chain is intentionally sequential:

1. com.sanctum.orbstack-engine-autostart runs orbctl start at boot
2. com.sanctum.openclaw.docker-startup runs ~/.openclaw/launch-after-docker.sh, which waits for the socket (docker info succeeds) before acting
3. Once the socket is live, it brings up the Home Assistant container (the signal-cli stack rode along until it was retired in the Colima cut)

The migration was uneventful, which is the highest compliment infrastructure work can receive. The Ecobee sensors appeared in HA’s discovery panel within seconds. They had been broadcasting the entire time. The VM just couldn’t hear them.

Caution

If you’re on Docker Desktop and your HomeKit integrations can’t discover devices: it’s not your config, not your firewall. It’s the VM boundary — mDNS packets don’t cross it, and never will. Switch to OrbStack or run HA on bare metal and the devices appear like they were there all along, because they were.

Sonos Integration

Sanctum manages 10 Sonos speakers across the haus, but not through HA’s built-in Sonos integration — that’s disabled. Instead a native Python service, the Sonos Bridge, runs directly on the Mac Mini, bypassing Docker entirely. It listens on port 1969 and exposes a REST API for speaker control, TTS announcements, and media playback; HA calls it via rest_command entries in configuration.yaml.

┌─────────────────────────────────────────────┐
│ Mac Mini (native)                           │
│                                             │
│  ┌───────────────────────────────────────┐  │
│  │ Sonos Bridge (port 1969)              │  │
│  │  SoCo → SSDP → 10 speakers on LAN     │  │
│  │  Qwen3-TTS → Yoda voice generation    │  │
│  └──────────┬────────────────────────────┘  │
│             │ REST API                      │
│  ┌──────────▼────────────────────────────┐  │
│  │ Docker: Home Assistant                │  │
│  │  rest_command.sonos_tts → :1969/tts   │  │
│  │  rest_command.sonos_announce → :1969  │  │
│  └───────────────────────────────────────┘  │
└─────────────────────────────────────────────┘

Why Not the HA Integration?

The HA integration needs advertise_addr and static host IPs to compensate for the bridge boundary, but Sonos speakers still have to reach back into the container for event callbacks — and that callback path breaks unpredictably after container restarts, networking warmups, and the occasional firmware update. We tried socat tunnels, socket_vmnet, and timed reload automations. None of it was reliable.

The native bridge uses SoCo directly on the Mac’s LAN interface. SSDP discovery works instantly. Speaker callbacks land on the Mac’s real IP. No tunnels, no NAT, no prayers.

HA REST Commands

HA scripts and automations call the bridge through two REST commands:

rest_command:
  sonos_tts:
    url: "http://host.docker.internal:1969/tts"
    method: POST
    content_type: "application/json"
    payload: '{"rooms": {{ rooms }}, "text": "{{ message }}", "severity": "{{ severity }}"}'
  sonos_announce:
    url: "http://host.docker.internal:1969/announce"
    method: POST
    content_type: "application/json"
    payload: '{"rooms": {{ rooms }}, "text": "{{ message }}", "severity": "{{ severity }}"}'

Severity maps to volume: low (30%), medium (50%), high (80%), critical (100%). The bridge handles TTS generation, audio file serving, and Sonos playback in a single call.

Text-to-Speech

The bridge generates speech through the sanctum-tts server on port 8008 — an OpenAI-compatible /v1/audio/speech endpoint with Qwen3-TTS behind it today (mlx-audio backend; XTTS-v2 retired 2026-04-19), resolved by model id so the backend can change without touching the bridge. It saves the WAV locally and tells Sonos to fetch it from http://<mac-lan-ip>:1969/<id>.wav. The voice is Yoda. There was a discussion. Yoda won.

Bridge Management

# Check bridge health
curl -s http://localhost:1969/health | python3 -m json.tool

# List all speakers
curl -s http://localhost:1969/speakers | python3 -m json.tool

# Manual TTS test
curl -X POST http://localhost:1969/tts \
  -H 'Content-Type: application/json' \
  -d '{"rooms": ["living_room"], "text": "Testing", "severity": "low"}'

# Restart bridge
launchctl kickstart -k gui/$(id -u)/com.openclaw.sonos-bridge

Tip

If a Sonos speaker changes IP (router reboot, LAN renumber), the bridge just shrugs. There is no longer a room-to-IP map to go stale — speakers are addressed by room name (the normalized Sonos player name) and rediscovered live via SSDP every 30 seconds (DISCOVERY_TTL). The static map was deleted when the LAN was renumbered on 2026-06-08, and nothing has missed it since. Firewalla DHCP reservations are still nice for sanity, but the bridge no longer needs them to stay correct.

Note

The HA Sonos integration config entry (01KHHZ98C0MYWPAGKBZM9K1ZB2) still exists in HA’s storage but is set to disabled_by: user. It can be re-enabled from HA’s Settings > Devices & Services if needed for rollback, though we’d recommend therapy first.

SSH Agent Forwarding

Some HA automations need SSH access to the VM. The Mac’s SSH agent socket at /run/host-services/ssh-auth.sock is mounted as a volume in the compose file, so scripts inside the container can ssh openclaw using the Mac’s loaded keys — no private keys ever stored in the container. Wrapper scripts live at ~/.openclaw/ha-scripts/ and exec SSH to the VM with agent forwarding enabled.

Network Configuration

The configuration.yaml carries network-specific settings so HA reports the right client IP behind the tunnel:

homeassistant:
  internal_url: "http://192.0.2.10:8123"
  external_url: "https://ha.example.net"

http:
  use_x_forwarded_for: true
  trusted_proxies:
    - 172.16.0.0/12
    - 192.168.64.0/20

The trusted proxies cover the OrbStack and Tailscale ranges, letting HA read the real client IP from X-Forwarded-For when a request arrives through the Cloudflare tunnel instead of attributing every visitor to the proxy.

Remote Access

There are two remote access paths into HA, each serving a different purpose — because one way in would have been too simple, and simplicity is what other people have.

Browser Access (Cloudflare Tunnel)

For the HA web UI from a browser, a Cloudflare tunnel provides HTTPS with Zero Trust access controls.

Component	Details
Tunnel name	manoir-hub (token-mode)
LaunchAgent	com.sanctum.tunnel
External URL	https://ha.example.net
Route	ha.example.net to localhost:8123
Auth	Cloudflare Access OTP

iPhone Companion App (Tailscale)

The HA Companion app cannot handle Cloudflare Access’s login page, so it connects via Tailscale instead. Tailscale provides end-to-end WireGuard encryption, so HTTPS is not needed.

Caution

With network_mode: host, HA binds 8123 on every interface (not just 127.0.0.1), which is exactly what Tailscale access needs. Safe because HA has its own auth, and LAN access is required anyway for HomeKit and Sonos.

Companion App Setup

1. Install Tailscale on iPhone and connect (do NOT enable exit node)

2. Install HA Companion

3. Open HA Companion → Settings → Companion App → Server & Connection

4. Configure connection URLs:

   Field	Value
   Internal URL	http://<mac-lan-ip>:8123
   External URL	http://<tailscale-ip>:8123

5. Under Internal Connection: add your haus Wi-Fi SSID so the app uses the LAN when haus

6. Enable Local Push for instant notifications on haus Wi-Fi

7. Test: turn off Wi-Fi briefly — the app should reconnect via Tailscale

Tip

Use http:// for both URLs, not https://. The internal hop is on your LAN; the external hop is already encrypted by Tailscale’s WireGuard tunnel. Adding TLS on top buys you cert management for zero security gain. Save your energy for problems that matter.

HomeKit Bridge

The HomeKit bridge runs on port 21063, allowing Apple Home app control of HA-managed devices.

Setting	Value
Port	21063
Pairing code	shown in HA → Settings → Devices & Services

The pairing code is generated per-bridge and lives in HA’s UI — never hardcode or commit it; a HomeKit code plus LAN access is all someone needs to pair. The bridge exposes selected devices to Apple Home while keeping the full HA device list in the web UI.

Management

Starting and Stopping

# Start HA
cd ~/.openclaw/homeassistant && docker compose up -d

# Stop HA
cd ~/.openclaw/homeassistant && docker compose down

# View logs
docker logs -f homeassistant

# Restart
cd ~/.openclaw/homeassistant && docker compose restart

Rollback

If the Mac Docker instance has issues, a rollback path exists to the VM:

1. Stop the Mac container: docker compose down
2. SSH to the VM: ssh openclaw
3. Start the VM instance: ~/.openclaw/ha-docker.sh recreate

Note

The VM still has a preserved HA configuration at ~/.openclaw/homeassistant/. The VM instance is stopped but not removed, making rollback straightforward. Think of it as a parachute — you hope you never need it, but you’d be a fool to cut it loose.
