Architecture Overview

At 02:47 on a Tuesday in April, an Xbox in the basement quietly joined the Wi-Fi. By 02:47:03, it was blocked at the router, a Signal message was sitting on a phone nine hundred kilometres away, a curfew violation was recorded in a SQLite database in a service named after the Sermon on the Mount, and a dashboard banner was already glowing amber. Nobody woke up. The haus, as of that moment, had noticed.

That is Sanctum working correctly. Thirty-eight services, two machines, one private bridge, and an ethos that matters more than any individual technical choice: we are building this like a body. It has bones — the parts that have stopped changing. It has flesh — the parts still growing new capabilities every week. It has nerves between the two, senses pointed at the outside world, and an immune response that sometimes wakes you up gently and sometimes does not wake you up at all. The docs below are the anatomy chart.

The Shape

Physically, Sanctum is a Mac Mini M4 Pro and a QEMU-headless Ubuntu VM running on it, connected by a private bridge100 interface on 10.10.10.0/24. The Mac is where hardware lives: Apple Silicon inference, Sonos bridging, Signal, HomeKit, and everything that has to touch a USB port or a microphone. The VM is where the agent cluster lives: six to nine specialized intelligences with no direct route to the internet. If the VM wants to reach the outside world, it asks the Mac nicely, and the Mac decides whether the request is reasonable. It is an air-gapped tenant with an indoor-plumbing privilege.

🔍 Hover to zoom

Conceptually, though, the physical diagram is the least interesting view. What makes Sanctum work is what runs inside those two boxes and how the pieces relate to each other — which is where the body metaphor becomes less cute and more operationally useful.

There’s also a less-physical principle that runs through the rest of this anatomy: the Council is plural on purpose. Each Jedi runs on a different model family by default — Yoda and Mundi on Claude Opus 4.7 via the haus’s Max subscription bridge, Qui-Gon on Qwen2.5-Coder-14B, Windu on Gemini 3.1 Pro, the privacy-critical seats (Cilghal, Mothma, Jocasta) on the local Qwen3.6 — because a council of one model wearing five robes returns one kind of answer regardless of who asks. See (Neuro)diversity is Paramount for the full doctrine and Principle 10 in The Living Force for the canonical short version.

The Bones

The bones are written in Rust and live in the sanctum-rs workspace. They are the parts of the system that have stopped redesigning themselves. Once a service crosses from the Python side of the haus — where features still sprout new limbs every week — into sanctum-rs/services/ and is built and deployed as the running launchd unit, it becomes structural: a single deploy binary, compile-time guarantees on its interfaces, and a slot that either holds or doesn’t.

As of this writing, two services actually meet that bar:

Bone	Port	What It Holds Up
sanctum-watchdog	—	The Living Force incarnate. Checks every service every ten minutes, self-heals the ones it can, escalates the ones it can’t.
sanctum-proxy	4040	The cloud-tier model router. Classifies requests, applies daily cost caps, falls back through a configured chain before giving up.

Several more services have Rust source scaffolded in sanctum-rs/services/ — sanctum-firewalla, sanctum-tts, sanctum-mlx, sanctum-memory, sanctum-server, sanctum-idle — but their runtimes are still the original Node or Python implementations on the ports you’d expect (:1984, :8008, :1337, :42069). The tools/rust_readiness.py harness tracks them honestly under the porting stage — it will not honour a graduated claim unless the binary actually exists at sanctum-rs/target/release/<name> on disk. Bones must be earned.

Note

The binary at ~/.sanctum/living-force.sh is four lines of bash that execs sanctum-watchdog. Living Force is the doctrine, sanctum-watchdog is the vertebra. They are indexed as aliases in the readiness registry so the two names resolve to the same thing.

The Flesh

The flesh is Python. It is how we find out what the service is before we carve it in Rust. Every service that currently sits in ~/.sanctum/force-flow/ or in the sanctum-screen-time repo is there because its feature shape is still moving — new credit mechanisms, new curfew edge cases, new channels added to the notification fan-out, a homework mode that keeps acquiring exemptions. Writing that in Rust would mean shipping less, slower, with fewer features that our family actually needs.

Muscle	Port	What It’s Still Figuring Out
force-flow	4077	The unified notification hub. iPhone push, Sonos TTS, Signal via signal-cli daemon, dashboard banners, macOS Notification Center. The channel list keeps gaining members.
screen-time	—	Curfew, wind-down, homework mode, credits, guests. Deployed alongside force-flow. The rules here change whenever a teenager finds a loophole.
memory-vault-mcp	—	MCP server in front of sanctum-memory. The consolidation pass is still tuning its heuristics.

Flesh hardens. The rust_readiness tool exists specifically so we can tell when a muscle has stopped twitching long enough to become a bone. The current readout (python3 tools/rust_readiness.py) puts force-flow and memory-vault-mcp in the hardening stage — feature velocity is slowing, but not zero. screen-time is still firmly organic. It will cross when the guest-approval flow stabilises, and not a day before.

The Nerves

Between bones and flesh runs a network of private pathways — bridge100 on the Mac–VM axis, and a short list of well-known local ports that services use to find each other without DNS. The rule is simple: no service reaches across the bridge for a remote HTTP call if there’s a local one that does the same job. Every cross-service conversation in Sanctum is a few hundred microseconds on the loopback interface, which means nothing interesting depends on the router’s mood at 3 AM.

 Mac Mini  10.10.10.1
 ├─ 1111   command-center
 ├─ 1234   LM Studio
 ├─ 1337   sanctum-mlx
 ├─ 1984   sanctum-firewalla
 ├─ 4040   sanctum-proxy
 ├─ 4077   force-flow
 ├─ 8008   sanctum-tts
 ├─ 8080   signal-cli daemon
 └─ 42069  sanctum-memory
         │
    bridge100  10.10.10.0/24
         │
 Ubuntu VM  10.10.10.10
 ├─ openclaw-gateway (systemd)
 ├─ Yoda, Windu, Qui-Gon,
 │  Cilghal, Mundi, Mothma
 └─ outbound → 10.10.10.1 only

The VM has no independent route to the outside world. Any external dependency — an Anthropic API call, a Gemini image generation, a git pull — happens through a Mac-side proxy or a Tailscale tunnel. This is either excellent security architecture or the opening scene of a containment thriller. It has been both.

Caution

The bridge IP on the Mac side is set at boot by an unsuffixed sudo ifconfig call in the VM-autostart LaunchAgent. A sudoers.d/vmnet-bridge entry allows it without a password prompt. If that file ever goes missing, the VM wakes up into a world with no bridge to anywhere and will handle the situation about as gracefully as you would.

The Senses

Each agent in the cluster is a specialized perception. Sanctum does not have one intelligence — it has a council of them, routed by the Smart Router to the model tier that fits their job. Cloud for long-horizon synthesis. Local-ops for tool use and code. Local-secure for anything that must never leave the machine.

Agent	Role	Model Tier
Yoda	Consigliere — absorbs everyone else’s escalations, advises the Don	council-brain — Opus 4.7 by default; smart-routed to local council-mlx for general chat and Opus 4.7 --effort max (Claude Team) for deep reasoning
Windu	Security master — Firewalla rules, PF policy, perimeter audits	Cloud (Opus 4.7)
Qui-Gon	Infrastructure — Docker health, systemd units, recovery	Local ops
Cilghal	Health — Apple Health, sleep, cognitive scaffolding	Local secure (Gemma4+LoRA)
Ki-Adi-Mundi	Finance — Triptyq deal flow, personal treasury	Local secure
Jocasta	Archivist — CRM, communications, long memory	Cloud
Mon Mothma	Operations — Force Flow + Living Force orchestration	Cloud
Ahsoka	Satellite — the agent that follows you when you leave the haus	Local ops
Tommy	Guardian Spirit — the dead cat with strong opinions about network segmentation	special

The routing rule is not democratic. Code and security stay on Opus regardless of budget; general chat can be downgraded to a cheaper model mid-conversation; health and fund data never leave the Mac. The proxy’s JSONL usage log is the ground truth for what actually ran, because an agent doesn’t always know which tier served its last turn.

The Immune System

Infrastructure rots. Entropy is undefeated. The whole reason sanctum-watchdog exists — and the whole reason the Living Force doctrine exists around it — is that a running system in a haus is a continuous low-grade medical emergency, and somebody has to keep checking the vitals. Every ten minutes, the watchdog walks the service catalogue, probes each port, asks each service whether it is well, and either (a) believes the answer, (b) restarts the service, or (c) writes a Force Flow notification aimed at a human. The correct outcome most nights is (a).

When the save is clean — a probe catches a drifting last_active timestamp two minutes before it metastasises into a cascade, the anomaly detector pins a root cause on the first retry — the watchdog does what Patrick Roy did to Sandström in the Forum, Game 4, 1993: glove save, wink at the shooter, skate to the bench. The cascade never lands. The dashboard stays green. The haus sleeps.

When the answer is wrong in interesting ways, the notification fans out through force-flow: the severity decides whether it’s a silent dashboard banner, a Sonos announcement that wakes the haus at 7 AM, an iPhone push, or — for the critical tier — a Signal message from Yoda’s account to a phone in California. Windu runs a parallel perimeter check over the Firewalla log; Qui-Gon watches the infrastructure layer; Cilghal watches your vitals rather than the machine’s. The council is, structurally, a distributed set of specialised antibodies with overlapping coverage. Allez, les Boys.

The Ethos

The thing we have learned, building this: a living system cannot be rewritten all at once, and it cannot be frozen all at once either. Rust is brittle if you reach for it too early; Python is expensive if you reach for it too late. So Sanctum runs on two substrates at the same time, and we accept that. We write new things in Python, where iteration is cheap and the shape of the service is still negotiable. We port old things to Rust, where deploys are single binaries and compile-time guarantees pay rent every day. The rust_readiness harness tells us the transition date. The Living Force doctrine tells us how to keep the thing alive during the transition.

The practical rule is this: you cannot tell a service’s maturity from its function, only from its velocity. Force Flow is mission-critical and still Python. sanctum-tts is cosmetic voice synthesis and already Rust. What graduates a service is not how important it is — it is how settled it is. Hardened and flexible at the same time is the only configuration that survives contact with a real family living in a real haus in Québec for a real decade. Welcome to City Montreal. Where we’re going, we don’t need roads — we need launchd, age keys, and a watchdog that doesn’t lie.

Tip

This overview is the ten-thousand-foot view. For the floor plan, walk through the Architecture sidebar in order: Living Force for the health doctrine, Language Maturity for the Python→Rust transition, Force Flow for the notification anatomy, Sanctum Proxy for the model routing, Services for the full port catalogue. Every room in the haus has its own page.
