mTLS Migration

mTLS Migration — two cryptographic handshake diagrams converging on port 1337, mutual certificates etched into the frame, amber glow from the CA stamp.

For a month the council ran dual-port: plain HTTP on :1337 with a bearer token (loopback-bypassed for sidecars), mTLS on :1338 for anyone who’d bothered to move. On 2026-04-22 the bearer was retired, the plain listener was taken off the air, and :1337 was promoted to mTLS. One port, one protocol, one authentication story — every client presents a certificate that chains to the internal Sanctum CA, and nothing else talks to the model.

This page is the record of what changed, why, and how to back out.

Before → after

	Before 2026-04-22	After 2026-04-22
`:1337`	plain HTTP + bearer (loopback bypass)	mTLS (cert-auth, no bearer)
`:1338`	mTLS (cert-auth)	retired — port unbound
Auth methods	bearer token OR mTLS cert	mTLS cert only
Sidecar fallback	mTLS if certs present, else bearer	mTLS required, hard-fail on missing certs
`--auth-token-file` in plist	yes	dropped
Bearer token on disk	`~/.sanctum/secrets/council-mlx.token`	`…token.retired-20260422` (7-day rollback window)

Why now

Five of six clients were already on mTLS after 2026-04-18. The sixth was sanctum-server, which had the mTLS code shipped but never flipped in config. Meanwhile bearer-via-loopback was doing real work: it covered guardian, canary, drift, parity-smoke, and any ad-hoc curl from the Mini itself. The thing keeping bearer alive on :1337 wasn’t a missing feature — it was the mlx_lm.server Python fallback that kept respawning on the same port, holding it hostage. Rebuilding from the Rust sanctum-mlx in the Mini’s existing plist never took, because Python won the port race.

On 2026-04-22 three changes landed in the same session:

com.sanctum.server-mlx.plist got renamed to .disabled-20260422, freeing :1337 permanently.
sanctum-mlx gained a --no-plain CLI flag (feat/proxy-hardening commit 831c40f) so the plain listener can be opted out of entirely. The loopback_bound invariant moved to AFTER TLS setup so a TLS loopback bind is sufficient for the guardian to probe.
The four cert-aware sidecar scripts dropped their bearer fallback paths. Missing ca.crt / client *.crt / client *.key is now a hard fail with exit 2. Silent downgrades are gone.

What starts automatically

Agent	Binds	Auth
`com.sanctum.mlx`	`:1337` on 127.0.0.1 + 100.0.0.25 (mTLS)	per-client cert signed by `~/.sanctum/certs/ca.crt`
`com.sanctum.council-guardian`	— (probe only)	guardian.crt to `:1337` every tick
`com.sanctum.council-canary`	— (probe only)	canary.crt to `:1337` every 10 min
`com.sanctum.council-parity-smoke`	— (probe only)	parity-smoke.crt to `:1337` nightly 03:00
`com.sanctum.council-canary-offbox` (MBP)	— (probe only)	council-offbox.crt to `100.0.0.25:1337` every 10 min

All cert files live under ~/.sanctum/certs/clients/. Same CA on Mini and MBP.

Five-minute sanity check

mTLS serves on :1337.

curl -sf --max-time 5 \
     --cacert ~/.sanctum/certs/ca.crt \
     --cert ~/.sanctum/certs/clients/sanctum-server.crt \
     --key  ~/.sanctum/certs/clients/sanctum-server.key \
     https://127.0.0.1:1337/v1/models | head -c 120

Returns a JSON {"data":[{"id":"Qwen3.6-35B-A3B-4bit-text",...}]}.

Plain HTTP refuses.
Terminal window
```
curl -v --max-time 3 http://127.0.0.1:1337/v1/models
```
Connection resets or TLS handshake error. A 200 here is a bug.
Old mTLS port :1338 is gone.
Terminal window
```
lsof -nP -iTCP:1338 -sTCP:LISTEN
```
No rows. Anything listening there is a stale process; kill it.
Sidecars are on mTLS.
Terminal window
```
tail -1 ~/.openclaw/logs/council-guardian.log
tail -1 ~/.openclaw/logs/council-canary.log
```
Both log "transport": "mtls" on every tick. If you see "plain-loopback", the script is an old copy — re-pull from the repo’s services/sanctum-mlx/deploy/.
Bearer token is retired.
Terminal window
```
ls ~/.sanctum/secrets/council-mlx.token*
```
Expect council-mlx.token.retired-20260422. The bare council-mlx.token path MUST NOT exist — if it does, something re-created it and bearer auth is live again.

Rollback

# On the Mini — bring back plain + bearer on :1337.
mv ~/.sanctum/secrets/council-mlx.token.retired-20260422 \
   ~/.sanctum/secrets/council-mlx.token

# Check out the old plist (pre-831c40f).
cd ~/Projects/sanctum-rs
git checkout c939513 -- services/sanctum-mlx/deploy/com.sanctum.mlx.plist
cp services/sanctum-mlx/deploy/com.sanctum.mlx.plist \
   ~/Library/LaunchAgents/com.sanctum.mlx.plist

# Reload the agent.
launchctl unload ~/Library/LaunchAgents/com.sanctum.mlx.plist
launchctl load   ~/Library/LaunchAgents/com.sanctum.mlx.plist

The sidecar scripts will still be the new mTLS-only versions, but that’s fine — they’ll keep working against the rolled-back server because the server now binds both plain (with bearer) AND mTLS (the old dual-port state).

What’s NOT in the migration

A few things that got asked about during execution and deliberately got left alone:

com.sanctum.triage binds 10.10.10.1:1337 on the bridge100 VM interface. It’s a separate Rust proxy that forwards VM requests to LM Studio at 127.0.0.1:1234. It has nothing to do with sanctum-mlx and didn’t need a touch. VMs reaching 10.10.10.1:1337 still hit triage and still reach LM Studio.
com.sanctum.drift-sentinel uses a Firewalla bearer for different auth. Unrelated.
com.sanctum.council-drift-offbox keeps flagging com.sanctum.mlx.plist drift until the repo’s committed plist catches up with prod — the 2026-04-22 commit fixed that by updating services/sanctum-mlx/deploy/com.sanctum.mlx.plist to match.

The retirement calendar

Date	Event
2026-04-17	mTLS landed alongside plain+bearer (dual-port)
2026-04-18 → 04-21	5 of 6 clients migrated to mTLS (canary, guardian, parity-smoke, off-box canary, off-box drift)
2026-04-22	plain listener retired, bearer token rotated to `.retired-20260422`
2026-04-29	Rollback window closes — delete the retired token file

Reminder: the Sanctum CA certs are valid through 2031. That’s the hard deadline for the next rotation.
