2026-04-18: The Off-Catalogue Audit

Three sittings, one question across all of them: what services are running that the watchdog doesn’t know about? No broken services. No crashes. No 4 AM underwear. Just an uncomfortable audit.

The answer, it turned out, was five.

Third Entry — Off-Catalogue Audit: Five Found, Five Registered

Watchdog before: 33/33 healthy. Watchdog after: 38/38 healthy.

A cross-reference of lsof -iTCP -sTCP:LISTEN against the watchdog catalogue revealed five sanctum-ecosystem services running without service YAMLs. All five were genuinely healthy. None appeared in the watchdog’s service list. The watchdog was blind to roughly fifteen percent of the running surface.

The Five

Service	Port	Root cause
OBLITERATUS ML Engine	7860	Registered in holocron-config.yaml and catalog.yaml, never got a ~/.sanctum/services/ YAML. Previous session fixed the Python 3.12 venv; nobody wrote the manifest.
Force Flow	4077	Has a LaunchAgent (com.sanctum.force-flow), documented in services.mdx, owned by Mothma. Started running before the watchdog YAML schema was standardized.
SanctumBridge	4078	FDA-privileged SQLite proxy for Jocasta-mcp. LaunchAgent exists, documented in jocasta-mcp.mdx. services.mdx still listed it at port 1455 — an older allocation. Runtime was on 4078.
LiveKit Server	7880	Yoda’s private voice server, bound to Tailscale IP only. LaunchAgent exists. YAML was never filed.
Jina Reranker	42070	Companion to memory-vault on 42069. Documented in cilghal.mdx as “Jina v2 reranking on :42070”. The port pair was always intended to travel together. Only one made it into the manifest.

Root Cause Pattern

Every off-catalogue service shared the same failure mode: LaunchAgent registration happened; watchdog YAML registration did not. The two-step was only completed halfway.

The pattern appears in three flavors:

1. Service predates YAML schema. Force Flow and SanctumBridge got LaunchAgents before the manifest format was standardized. Nobody backfilled.
2. Service was fixed but not registered. OBLITERATUS got its venv repaired last session. The fix closed the ticket but left the watchdog blind, because the session’s focus was the Python interpreter, not the catalogue.
3. Companion service forgotten. Memory-vault has a YAML. Its paired reranker doesn’t. When you think of them as one unit, you write one manifest.

The common thread: the LaunchAgent is the developer artifact; the watchdog YAML is the operations artifact. They live in different directories, get created by different people (sometimes different agents), and there is no gate between them. You can have a perfectly healthy, fully supervised, LaunchAgent-managed service that the watchdog has never heard of.

Deadpool Protocol Port Audit

All five ports were clean — no reassignment needed.

Port	Service	Note
7860	OBLITERATUS	Gradio default. Registered in holocron-config.yaml under sectors.obliteratus.
4077	Force Flow	M*A*S*H 4077th — field hospital that triaged casualties with gallows humor.
4078	SanctumBridge	Adjacent to Force Flow. FDA-proxy port. Collision-free.
7880	LiveKit	LiveKit canonical default. Bound to Tailscale IP (100.0.0.25) only — no LAN or WAN exposure. RTC TCP companion on 7881.
42070	Reranker	Pair port to memory-vault’s 42069. Deliberate adjacency.

The catalogue-sync-check.sh Guardrail

Created /Users/neo/Documents/Claude_Code/tools/catalogue-sync-check.sh to keep this class of drift from returning quietly.

The script does three things:

1. Queries the watchdog API (/health) and extracts all ports it tracks.
2. Runs lsof -iTCP -sTCP:LISTEN and collects all listening TCP ports.
3. Cross-references the two lists. Prints any port listening but not in the watchdog catalogue, filtered against a maintained ignore list of system ports (22, 80, 443, 631), macOS services (Raycast and ControlCenter on 5000, 7000, 7265), Cloudflare’s internal listener (20241), and documented companion or internal ports.

After this session, the script outputs: (none — catalogue is fully in sync).

When to run it:

• After any manual nohup ... & or launchctl load that isn’t accompanied by a service YAML commit.
• Before writing a living-force entry — it’s the audit step that tells you what to write about.
• After a boot or LaunchAgent batch-load, to catch anything that came up without a manifest.

The INTERNAL_PORTS array is self-documenting: every excluded port has an inline comment explaining the exclusion. If a port ever moves off that list, it will immediately start appearing in output.

The two-step registration will always try to drift

LaunchAgents are a developer instinct. Watchdog manifests are an operational discipline. The guardrail script exists because the gap between the two is the exact shape most often missed at 11 PM.

Post-Session Watchdog State

overall: healthy, 38/38 services healthy (up from 33/33 at session start — five new services registered, all confirmed healthy before registration).

Newly tracked: obliteratus, force-flow, sanctum-bridge, livekit-server, reranker.

Fourth Entry — Stale Claims, Corrected

Watchdog healthy. Which meant the next question was also uncomfortable: which docs still believed the pre-audit world?

What Was Wrong

A lot, actually. The Q2 catalog rename (xtts → xtts_server, gateway → openclaw_gateway, mlx_server → council_mlx) had landed in the runtime but the docs had been backfilling it piecemeal. The 33 → 38 service count update from the morning’s audit hadn’t propagated anywhere. Port 1455 was still in services.mdx as SanctumBridge’s home, three days after the runtime moved to 4078. A duplicate Hawkeye codename at 4007 was sitting next to the real Hawkeye at 4077 like nobody would notice.

What Changed

A single docs-audit sweep fixed eighteen stale claims across architecture/services.mdx, architecture/jocasta-mcp.mdx, reference/instance-yaml.mdx, reference/launchagents.mdx, operations/operational-state.mdx, operations/runtime-drift-audit.mdx, and operations/feature-status-matrix.mdx. The Q2 renames were propagated everywhere they were missing. Port 4078 replaced 1455 for SanctumBridge. The 4007 duplicate was retired in favor of 007 — Licensed to Ping. The “32 rendered manifests” and “33 manifests as current” claims were updated to 38 with timestamps anchoring what “current” meant.

Two code files were also nudged to match the docs rather than the other way around:

• run_sanctum.sh had ./.venv/bin/obliteratus left over from before the Python 3.12 venv migration. Changed to ./venv/bin/obliteratus (non-hidden venv).
• sanctum/instance.yaml.example was updated to match the Q2 rename keys that the live instance.yaml already used (xtts_server, council_mlx, openclaw_gateway).

Deadpool Protocol Expansion

Added a ### The Deadpool Protocol subsection to the Port Summary section in services.mdx, codifying the five acceptable port-naming forms (palindromes, pop-culture, math constants, paired wit, upside-down calculator), the dry-acknowledgment exception for default or sequential ports, and the new-port PR mandate (port_lore: in YAML plus gag in PR description).

Added # port_lore: <one sentence> comments to 27 service YAMLs in ~/.sanctum/services/ that were missing them. The services with no port (cloudflare, dench, model-scout, post-boot, orbi-bridge, tailscale, tommy, triage, vm, watchdog, icloud-filer) were skipped — no port, no port joke, no problem.

CONTRIBUTING.md, Also Stale

• Named-port list updated from 1337, 1977, 1984, 4040, 4077, 8008, 42069 to include 4078, 10101, 31416, 42070.
• Added step 6 of port selection: the # port_lore: comment mandate — placed directly under port:, optional for the watchdog, required for human dignity.
• Added Technical Accuracy entries for the 38-service catalogue count, the catalogue-sync-check.sh guardrail, the OBLITERATUS venv/ + Python 3.12 requirement, and the Q2 renames.

Aspirational vs. Actual

No new :::caution[Roadmap] callouts were needed. Every doc claim reviewed this session maps to implemented behavior. The run_sanctum.sh venv path was the only actual divergence — fixed inline, because the fix was a one-line correction to match already-documented behavior, not an aspirational promise.

Post-Session State

Watchdog unchanged at 38/38 (this was a docs and code audit, not a service fix). All corrected doc claims now match the live system. The “SanctumBridge port discrepancy” gotcha from the third entry is resolved.

Fifth Entry — Session Close

End-of-day close-out: E2E test sweep, logical commits, backup, and the final living-force entry for the day.

E2E Results

Watchdog bulk check ran after a manual POST /check. The most recent snapshot (20:53 UTC) showed 37/38 healthy with health-center as the sole degraded root cause. By close-out time, health-center (port 2222, node PID 54163) had recovered on its own — the triage remediation already succeeded. Catalogue sync check came back clean: 38 services catalogued, zero uncatalogued listeners.

Flow	Description	Result
Flow 1	Watchdog → /check/council-mlx round-trip	Pass
Flow 2	council-mlx /health	Pass — {"status":"ok"}
Flow 3	voice-agent liveness (:1138/health)	Pass
Flow 3b	xtts-server liveness (:8008/health)	Pass
Flow 4	memory-vault (:42069/health)	Pass — version 0.1.0
Flow 4b	reranker (:42070/health)	Pass — jina-reranker-v2-base-multilingual, loaded
Flow 5	force-flow /screen/status	Pass — curfew logic active
Flow 6a	graphiti tunnel (:31416/health)	Pass — neo4j connected
Flow 6b	network-control tunnel (:4007/health)	Pass — DNS connected, Orbi configured
Flow 7	OBLITERATUS (:7860/)	Pass — Gradio UI live
Catalogue sync	tools/catalogue-sync-check.sh	Pass — 38 services, 0 uncatalogued

Known Exceptions — Not Fake Green

Four flows were skipped for documented infra reasons, not swept under the rug:

• voice-agent /tts-check — endpoint doesn’t exist on port 1138. Voice-agent liveness confirmed separately via /health. TTS round-trip was not tested end-to-end.
• obliteratus /api/queue/status — returns 404 because the Gradio queue endpoint isn’t exposed in this build. Root UI returns 200; the ML engine is live.
• Watchdog /status/all — returns empty body after the initial stale snapshot. /status (uptime, checks_run) works normally; the detail endpoint appears to require an in-progress check cycle to populate. All service health confirmed via individual probes instead.
• manoir SSH backup — the SSH agent had no identities loaded (key requires Keychain passphrase, not available in headless session). The remote tarball pull from manoir was not possible. Git bundle fallback used.

Commits

Five commits in the main workspace plus one in the sanctum-docs submodule:

SHA	Scope	Description
03f5849	sanctum-docs	docs(services): Q2 rename corrections + new service entries
d44e110	main	test(sanctum): Q2 rename fixes in test harness
b14184a	main	fix(obliteratus): venv path correction in run_sanctum.sh
a4b1df8	main	chore(sanctum): Q2 service key renames in config + calibration
3b446ae	main	feat(tools): catalogue-sync-check guardrail script
5e5cb51	main	chore(sanctum-docs): bump submodule pointer for Apr 18 docs rewrite

Backup

Mechanism: git bundle create (fallback — manoir SSH unavailable, SSH agent empty). Artifact: /Users/neo/Backups/sanctum-20260418.bundle (68.4 MB). Contents: full workspace git history — all branches, all refs, all Apr 18 commits. Integrity: verifiable via git bundle verify.

The documented mechanism — tools/backup-sanctum.sh — pulls a ~/.sanctum/ plus LaunchAgents tarball from manoir via SSH, which requires an unlocked SSH key in the agent. The bundle fallback is documented in the backup script’s instructions and captures the workspace git history completely. The manoir-side config layer will be covered by the next scheduled weekly backup (Saturday 04:30, com.sanctum.backup).

Post-Session State

Watchdog: 38/38 healthy at close (health-center recovered via triage remediation during the session). All service flows verified healthy or documented as known exceptions. All Apr 18 changes committed in logical groups. Catalogue fully in sync — no shadow services. Docs and code in alignment.

Apr 18 sanctum session complete.

Gotchas for Next Time

• Two-step registration is a trap. Creating a LaunchAgent and starting a service is step one. Filing ~/.sanctum/services/<name>.yaml is step two. The watchdog only sees step two. They are not linked. They will drift unless both are done in the same session.
• HTTP-monitored services don’t appear in the port sync check. The watchdog health message says “HTTP 200” rather than “port X open” for services checked via HTTP (obliteratus, tommy, navigator-bridge). The sync-check extracts ports from the message text, so these don’t show up as covered. They’re tracked in the INTERNAL_PORTS ignore list with inline comments.
• Companion ports need companion YAMLs. If a service has a paired secondary port (reranker + memory-vault, livekit-server + token-minter), check whether the companion also needs a YAML. The fact that one half exists doesn’t mean the other half was filed.
• Bootstrap health-tunnel process. On each boot, sanctum-bootstrap.sh may start its own health-tunnel with different port-forwarding args than the current on-disk plist. After running sync_runtime_calibration.py, always launchctl unload then load to replace the running tunnel with the new config. The bootstrap process will keep running with stale args until explicitly killed.
