SanctumBridge

A small Mac app bundle at a stone gate, four SQLite scrolls flowing through a thin pipe into it

There’s a class of macOS databases that nothing should ever need to touch directly — chat.db, Calendar.sqlitedb, ChatStorage.sqlite, AddressBook-v22.abcddb. Apple’s TCC framework guards them behind Full Disk Access, the most powerful single grant on the system. Granting FDA to your terminal is a rite of passage and, like every rite of passage, the kind of thing you eventually stop questioning. SanctumBridge is the answer to “why are we granting FDA to terminal at all?”

It’s a single .app bundle running on 127.0.0.1:4078 whose entire job is to read four SQLite files and answer POST /bridge/query over loopback HTTP. Every other process — Jocasta, the council agents, Yoda’s tool calls — gets to be FDA-clean. They just speak HTTP to the bridge.

Why a `.app` bundle and not a script

TCC attaches Full Disk Access to a signed code identity. Granting FDA to Terminal.app extends to every shell child it spawns — but that scope is wider than it looks and easily lost when the shell host changes (iTerm vs Terminal vs a tmux reattach). An app bundle with its own CFBundleIdentifier carries its own TCC entry, so the grant survives reboots, shell reorganizations, and Homebrew updates that swap node versions.

The bundle is a 94-line C launcher (launcher/main.c, ~56 lines once you strip the header comment) that posix_spawns Node against Resources/bridge/server.js. The launcher itself links only libSystem + Foundation — but its code identity isn’t the whole story, because it execs /usr/local/bin/node, and that path is the load-bearing decision. /usr/local/bin/node is the Node.js Foundation .pkg install: signed, notarized, and pinned to a path that never moves. Homebrew node was retired from the bridge on 2026-05-21 precisely because TCC keys the FDA grant to a binary path, and brew’s versioned Cellar path churns on every upgrade. The .pkg path stays put forever, so the grant does too.

API

POST /bridge/query
Content-Type: application/json

{"db": "imessage|whatsapp|contacts|calendar", "sql": "...", "params": []}

Returns {"rows": [...], "count": N, "elapsed_ms": M} or {"error": "..."}. SELECT and PRAGMA only — anything that mutates data is rejected at the server, not at the database. The bridge is read-only by construction.

GET /health

Returns {"status": "ok", "service": "sanctum-bridge", "version": "1.0", "port": <n>, "started_at": "<iso>", "uptime_s": <n>, "pid": <n>}.

Resolved databases

`db`	Path
`imessage`	`~/Library/Messages/chat.db`
`whatsapp`	`~/Library/Group Containers/group.net.whatsapp.WhatsApp.shared/ChatStorage.sqlite`
`calendar`	`~/Library/Group Containers/group.com.apple.calendar/Calendar.sqlitedb`
`contacts`	the largest `~/Library/Application Support/AddressBook/Sources/<uuid>/AddressBook-v22.abcddb`

The contacts resolver picks by file size on purpose. macOS keeps one folder per address book account (iCloud, On My Mac, etc); most are 2-record stubs and the iCloud one is the 7,500-record real source. Picking the first folder lexically, which is what the original implementation did, silently returned the stub on every machine where iCloud Contacts was enabled. That bug was fixed 2026-04-28 and the contacts resolver is now load-bearing in the Yoda truth-telling chain — a 2-record contacts table looks like an empty result, which the model would then need to not fabricate around.

Calendar is special

The on-disk Calendar.sqlitedb on macOS Sequoia (15) and Tahoe (16) is a stale snapshot, not an empty one — which is the more dangerous of the two. It holds thousands of rows: subscribed holiday calendars stretching out to 2037, a fossil layer of old personal events, the usual scatter of birthdays. What it does not hold is anything recently synced — query it for today and you get nothing, because the live event store routes through the EventKit XPC service and stopped writing to this file generations of macOS ago. Jocasta-mcp solves this with a separate Swift bridge (~/.sanctum/bin/jocasta-eventkit) that calls EKEventStore.predicateForEvents — SanctumBridge isn’t involved in the calendar path on modern macOS, even though it can technically open Calendar.sqlitedb. Querying calendar through the bridge returns that stale layer in full conviction. That’s deliberately noisy: the freshness defect lives in Apple’s storage layer, not in the bridge, and an answer that’s obviously a decade out of date is safer than a plausible one the model might smooth over.

Source

Ogilthorp3/sanctum-bridge — make build produces the .app bundle from launcher/main.c and bridge/server.js. make install drops it into ~/Applications/. Bundle ID stays ai.openclaw.denchclaw so the existing TCC FDA grant carries across rebuilds.

The repo was reconstructed 2026-04-28 from the live deployed bundle. The original source had been inline-edited into the .app and never committed — the running binary on the Mac Mini was the only artifact, not on either Mac’s filesystem, in any restic snapshot, on any external drive, or in any Trash. The launcher was reverse-engineered from its strings(1) output — a binary that strips down to a single-digit handful of strings doesn’t hide much — and the legacy bash launcher (preserved as launcher/SanctumBridge.bash.legacy); the bridge/server.js is the live production code with the contacts-resolver fix folded in.

The bundle is also now in the restic backup paths (~/Backups/sanctum-backup.sh) so a future inline-edit incident has somewhere to recover from.

Configuration

The bridge reads SANCTUM_BRIDGE_PORT from the environment (default 4078). The LaunchAgent at ~/Library/LaunchAgents/com.sanctum.bridge.plist doesn’t hardcode the port — it shells out through ~/.sanctum/bin/sanctum-bridge.sh, which resolves the port via sanctum_get services.sanctum_bridge.port from ~/.sanctum/instance.yaml. Single source of truth, doctrine-clean.

The jocasta-mcp client side mirrors this: SANCTUM_BRIDGE_URL is set by ~/.sanctum/bin/jocasta-mcp-stdio.sh from the same YAML key. Changing the port is one edit to instance.yaml, then launchctl kickstart -k and the openclaw-gateway restart — no plist edits, no source code changes.

DenchClaw, briefly

The bundle ID ai.openclaw.denchclaw is a fossil. The Mac-side stack was called DenchClaw for a few months in early 2026 before the Sanctum rename — Judi Dench as M, running operations from headquarters while Bond is in the field, while the agents are deployed across the infrastructure. The bundle ID was kept stable across the rename because changing it invalidates the TCC grant, and re-prompting for FDA on every reboot is the kind of thing Bert refuses to live with.
